1.6.2.2 CWDM MUX/DEMUX with Single Fiber Specifications
Table 8: CWDM MUX/DEMUX with Single Fiber Specifications
Parameter 8 Channels 16 Channels
CWDM Passband (nm) 1471-1611 1311-1611
Channel Spacing (nm) 20 20
Link Loss (MUX+DEMUX) (dB) ≤6 ≤7
Adjacent Channel Isolation (dB) ≥30 ≥30
Non-Adjacent Channel Isolation (dB) ≥45 ≥45
Express Channel Wavelength (nm) • 1291+/-6.5
• 1311+/-6.5
• 1271+/-6.5
• 1291+/-6.5
Express Channel Link Loss (dB) ≤1.5 ≤1.5
Connector Type Channels LC/UPC LC/UPC
Connector Type COM SC/UPC SC/UPC
1.6.3 CWDM OADM Specifications
Table 9: CWDM OADM Specifications
Parameter 1 Channel 2 Channels 4 Channels
CWDM Passband (nm) 1331-1611 1331-1611 1331-1611
Channel Spacing (nm) 20 20 20
Link Loss (Add/Drop) (dB) ≤1.6 ≤2.4 ≤4.0
Adjacent Channel Isolation (dB) ≥30 ≥30 ≥30
Non-Adjacent Channel Isolation (dB) ≥40 ≥40 ≥40
Operating Temperature (°C/°F) 0° to 70°C/
32° to 158°F
0° to 70°C/
32° to 158°F
0° to 70°C/
32° to 158°F
Connector Type Channels LC/UPC LC/UPC LC/UPC
Connector Type COM SC/UPC SC/UPC SC/UPC
1.6.4 DWDM MUX/DEMUX Specifications
1.6.4.1 DWDM MUX/DEMUX with Dual Fiber Specifications
Table 10: DWDM MUX/DEMUX Dual Fiber Specifications
Parameter 4 Channels 8 Channels 16 Channels 40 Channels
DWDM Passband
(Channels)
CH28-CH31 CH28-CH35 CH20-CH35 CH20-CH59
Channel Spacing (GHz) 100 GHz 100 GHz 100 GHz 100 GHz
