INTRODUCTION
PACKETLIGHT NETWORKS PL-300 3.2 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION. ALL RIGHTS RESERVED. PAGE 29
Parameter 4 Channels 8 Channels 16 Channels 40 Channels
Link Loss
(MUX+DEMUX) (dB)
≤4 ≤4 ≤7 ≤7
Adjacent Channel
Isolation (dB)
≥26 ≥26 ≥26 ≥26
Non-Adjacent Channel
Isolation (dB)
≥45 ≥45 ≥35 ≥35
Express Channel
Wavelength (nm)
1511+/-6.5 1511+/-6.5 1511+/-6.5 1511+/-6.5
Express Channel
Link Loss (dB)
≤1.5 ≤1.5 ≤1 ≤1
Connector Type LC/UPC LC/UPC LC/UPC LC/UPC
1.6.4.2 DWDM MUX/DEMUX with Single Fiber Specifications
Table 11: DWDM MUX/DEMUX 100 GHz Single Fiber Specifications
Parameter 8 Channels 16Channels 40 Channels
DWDM Passband (Channels) CH28-CH35 CH20-CH35 CH20-CH59
Channel Spacing (GHz) 100 GHz 100 GHz 100 GHz
Link Loss (MUX+DEMUX) (dB) ≤6 ≤7 ≤7
Adjacent Channel Isolation (dB) ≥26 ≥26 ≥26
Non-Adjacent Channel Isolation (dB) ≥45 ≥35 ≥35
Express Channel Wavelength (nm) • 1511+/-6.5
• 1491+/-6.5
• 1511+/-6.5
• 1491+/-6.5
• 1511+/-6.5
• 1491+/-6.5
Express Channel Link Loss (dB) ≤1.5 ≤1 ≤1
Operating Temperature (°C/°F)
-20° to +85°C/
-4° to +185 °F
-20° to 85°C/
-4° to 185°F
-20° to 85°C/
-4° to 185°F
Connector Type Channels LC/UPC LC/UPC LC/UPC
Connector Type COM SC/UPC SC/UPC SC/UPC
Table 12: DWDM MUX/DEMUX 50 GHz Single Fiber Specifications
Parameter 88 Channels
DWDM Passband (Channels) 17C-60H
Channel Spacing (GHz) 50 GHz
Link Loss (MUX+DEMUX) (dB) ≤6
Adjacent Channel Isolation (dB) ≥26
Non-Adjacent Channel Isolation (dB) ≥45
Express Channel Wavelength (nm) • 1511+/-6.5
• 1491+/-6.5
