INTRODUCTION
PACKETLIGHT NETWORKS PL-300 3.2 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION. ALL RIGHTS RESERVED. PAGE 31
1.6.5 DWDM OADM Specifications
Table 15: DWDM OADM Specifications
Parameter Value
DWDM Passband (Channels) ITU DWDM Grid
Add/Drop Channels 1-4
Channel Spacing (GHz) 100 GHz
Link Loss (Add+Drop) (dB) ≤2.3
Adjacent Channel Isolation (dB) ≥25
Non-Adjacent Channel Isolation (dB) ≥45
OSC Channel Wavelength (nm) 1511+/-6.5
Operating Temperature (°C/°F) 0° to +70°C/+32° to +158°F
Connector Type Channels LC/UPC
Connector Type COM/EXP SC/UPC
1.6.6 DCM Specifications
Table 16: DCM Specifications
Range Channel Spacing Operation BW Insertion Loss
40 Km 100 GHz > 40 GHz < 1 dB
60 Km 100 GHz > 40 GHz < 1 dB
80 Km 100 GHz > 40 GHz < 1 dB
100 Km 100 GHz > 40 GHz < 1.5 dB
120 Km 100 GHz > 40 GHz < 1.5 dB
220 Km 100 GHz > 30 GHz < 1.5 dB
400 Km 100 GHz > 30 GHz 5.0 dB
