PacketLight Networks PL-300 - Figure 15: PL-300 DWDM-1 M-4 W-1 C-2 F

INTRODUCTION
PACKETLIGHT NETWORKS PL-300 3.2 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION. ALL RIGHTS RESERVED. PAGE 14
PL-300
Model
MUX
Type
MUX
#
MUX
WLs
#
COM
Ports
#
COM
Fiber
Type
Clients
#
MUX1
WLs
MUX2
WLs
MNG1
WL
MNG2
WL
DWDM-
2M-8W-
2C-1F
DWDM 2 8 2 Single 8
(4+4)
CH28-CH35 CH28-CH35 1511 1491
DWDM-
2M-16W-
2C-1F
DWDM 2 16 2 Single 16
(8+8)
CH20-CH35 CH20-CH35 1511 1491
DWDM-
2M-16W-
1C-1F
DWDM 2 16 1 Single 16 CH21-CH36 CH45-CH60 1491 1511
DWDM-
2M-44W-
1C-1F-
50G
DWDM 2 44 1 Single 44 • 15H-37C
• 40C-61H
(See
Note 1)
N/A 1511 N/A
DWDM-
1M-88W-
1C-1F-
50G-1D
DWDM 1 88 1 Single 88
(See
Note 2)
17C-60H
(See
Note 1)
N/A N/A N/A
NOTE:
1. 50 GHz spacing
2. Unidirectional
1.5.3.1 DWDM MUX/DEMUX Models
1. PL-300 DWDM-1M-4W-1C-2F:
 Single passive optical MUX/DEMUX module with four wavelengths
 The MUX/DEMUX module has an additional channel for the management
OSC channel
 One COM port with dual fiber
Figure 15: PL-300 DWDM-1M-4W-1C-2F
