PacketLight Networks PL-300 - Technical Specifications; General Specifications; Figure 31: PL-300 DCM4; Table 6: General Specifications

INTRODUCTION
PACKETLIGHT NETWORKS PL-300 3.2 INSTALLATION AND CONFIGURATION MANUAL
CONFIDENTIAL AND PROPRIETARY INFORMATION. ALL RIGHTS RESERVED. PAGE 26
3. PL-300 DCM4-<n>K:
 Four passive optical DCM modules
 Four In/Out port
 Supports a distance of up to <n> km
Figure 31: PL-300 DCM4
1.6 Technical Specifications
This section describes the PL-300 technical specifications.
1.6.1 General Specifications
Table 6: General Specifications
Client Ports Number of Ports Up to 44 ports
Connectors LC
COM Ports Number of Ports Up to two ports
Connectors LC or SC
EXP Ports
NOTE: Applicable only for OADM
models.
Number of Ports Up to two ports
Connectors LC or SC
