7.7.10 Communication Function 2: General-purpose Serial Communication
(Ethernet)
The supplement is described below to conduct Ethernet communication by the general-purpose
serial communication.
Reference: <7.4 Communication Function 2: General-purpose Serial Communication>
Overview
Data can be sent and received between the FP-X and an external device using Ethernet.
Data is read from and written to an external device connected to Ethernet by means of FP-X data
registers, and the programs are required for the FP-X.
Outline of operation
Connection with an external device is established using the general-purpose serial communication
(Ethernet). Number of connection is one.
Select either the client mode or server mode.
In case of the client mode, connection is established by the AFPX-COM5 for a predetermined IP
address after turning on the power supply of the FP-X.
There are Send dataand Receive datafor the data transfer with an external device.
