4.2 Allocation of FP-X Control Unit
The I/O allocation of FP-X control unit is fixed.
I/O numbers
Type of control unit
Number of allocation
I/O number
FP-X C14 control unit
Input (8 points)
X0 to X7
Output (6 points)
Y0 to Y5
FP-X C30 control unit
Input (16 points) X0 to XF
Output (14 points)
Y0 to YD
FP-X C60 control unit
Input (32 points)
X0 to XF
X10 to X1F
Output (28 points)
Y0 to YD
Y10 to Y1D
4.3 FP0 Expansion Unit Allocation
The FP-X expansion unit is installed on the right side of the FP-X control unit.
I/O numbers (when installed as the first expansion unit)
Type of expansion unit
Number of allocation
I/O number
FP-X E16 expansion I/O unit
Input (8 points)
X300 to X307
Output (8 points) Y300 to Y307
FP-X E30 expansion I/O unit
Input (16 points)
X300 to X30F
Output (14 points) Y300 to Y30D
FP-X E16X expansion input unit
Input (16 points)
X300 to X30F
FP-X E14YR expansion output unit Output (14 points) Y300 to Y30D
Note) E16 cannot be connected on the right side of E16.
