4.5 I/O Allocation of FP-X Add-on Cassette
The FP-X add-on cassette is mounted on the FP-X control unit.
I/O numbers
Type of control unit
I/O No.
Cassette
mounting part 1
Slot 0
Cassette
mounting part 2
Slot 1
Communication
cassette
FP-X communication
cassette
AFPX-COM1 − −
FP-X communication
cassette
AFPX-COM2 − −
FP-X communication
cassette
AFPX-COM3 − −
FP-X communication
cassette
AFPX-COM4 − −
FP-X communication
cassette
AFPX-COM5 − −
FP-X communication
cassette
AFPX-COM6 − −
Application
cassette
FP-X analog input
cassette
Note2)
AFPX-AD2
CH0 WX10
CH1 WX11
CH0 WX20
CH1 WX21
FP-X analog output
cassette
AFPX-DA2
CH0 WY10
CH1 WY11
CH0 WY20
CH1 WY21
FP-X analog I/O
cassette
AFPX-A21
CH0 WX10
CH1 WX11
WY10
CH0 WX20
CH1 WX21
WY20
FP-X thermocouple
cassette
AFPX-TC2
CH0 WX10
CH1 WX11
CH0 WX20
CH1 WX21
FP-X RTD cassette AFPX-RTD2
CH0 WX10
CH1 WX11
CH0 WX20
CH1 WX21
FP-X input cassette
AFPX-IN8
From X100
From X200
FP-X output cassette
AFPX-TR8
From Y100
From Y200
FP-X output cassette AFPX-TR6P From Y100 From Y200
FP-X I/O cassette AFPX-IN4T3
From X100
From Y100
From X200
From Y200
FP-X pulse I/O cassette
Note3)
AFPX-PLS
From X100
From Y100
From X200
From Y200
FP-X master memory
cassette
AFPX-MRTC − −
Note1) There is no I/O for the communication cassette and master memory cassette.
Note2) Digital conversion values are K0 to 4000. As the resolution is 12 bits, upper 4 bits are always 0.
Note3) The pulse I/O cassette cannot be used with the Tr type.
