5.2 Installation Using Expansion Cable
The FP-X expansion unit and the FP-X expansion FP0 adapter are connected to the control unit using
the exclusive expansion cable.
-The expansion cable (AFPX-EC08) is packaged with the expansion unit and expansion FP0 adapter.
(It can be purchased separately.) The expansion cables (AFPX-EC30 and AFPX-EC80) are sold
separately.
Note:
-The total length of the expansion cables should be within 160 cm.
-When using the expansion cable (AFPX-EC30 or EC80), keep it away from the devices and wirings
generating noises as much as possible.
