Panasonic AFPX-C30T User Manual

A: Available, N/A: Not available
Restrictions on control unit
FP-X C14
FP-X C30
FP-X C60
FP-X C30
FP-X C60
FP-X C60
Type of add-on cassette
Cassette
mounting
part 1
Cassette
mounting
part 2
Expansion
connector
part
Commu-
nication
cassette
FP-X Communication cassette AFPX-COM1 A N/A
The add-on
cassette
cannot be
installed.
FP-X Communication cassette
AFPX-COM2
A
N/A
FP-X Communication cassette AFPX-COM3 A N/A
FP-X Communication cassette
AFPX-COM4
A
N/A
FP-X Communication cassette AFPX-COM5 A N/A
FP-X Communication cassette
AFPX-COM6
A
N/A
Appli-
cation
cassette
FP-X Analog input cassette AFPX-AD2 A A
FP-X Input cassette
AFPX-IN8
A
A
FP-X Analog output cassette AFPX-DA2 A A
FP-X Analog I/O cassette
AFPX-A21
A
A
FP-X Thermocouple cassette AFPX-TC2 A A
FP-X RTD cassette
AFPX-RTD2
A
A
FP-X Output cassette AFPX-TR8 A A
FP-X Output cassette
AFPX-TR6P
A
A
FP-X I/O cassette AFPX-IN4T3 A A
FP-X Pulse I/O cassette
AFPX-PLS
A
Note5)
A
Note5)
FP-X Master memory cassette AFPX-MTRC A
Note1)
A
Note1)
Note:
1. Only one FP-X master memory cassette AFPX-MRTC can be installed. If 2 units are installed, E26
(user ROM error) will occur.
2. One application cassette can be installed in either cassette mounting part 1 or 2 of C30/C60.
3. As only one communication cassette can be installed in the cassette mounting part 1, it should be
installed on the application cassette if the application cassette is installed. (It cannot be installed in the
cassette mounting part 2.)
4. The add-on cassette cannot be installed in the expansion connector part of C60 (it does not work).
5. The pulse I/O cassette cannot be installed on the FP-X Tr type.
