FP-X Ry type
Item
Add-
ress
Name Default value Description
Pulse I/O
cassette
settings
(HSC/
PLS)
400
High-speed
counter
settings
(X100 to X102)
CH8:
Do not set
input X100 as
high-speed
counter
Do not set input X100 as high-speed counter.
Two-phase input (X100, X101)
Two-phase input (X100, X101), Reset input
(X102)
Incremental input (X100)
Incremental input (X100), Reset input (X102)
Decremental input (X100)
Decremental input (X100), Reset input (X102)
Incremental/decremental input (X100, X101)
Incremental/decremental input (X100, X101),
Reset input (X102)
Incremental/decremental control input (X100,
X101)
Incremental/decremental control input (X100,
X101), Reset input (X102)
CH9:
Do not set
input X101 as
high-speed
counter
Do not set input X101 as high-speed counter.
Incremental input (X101)
Incremental input (X101), Reset input (X102)
Decremental input (X101)
Decremental input (X101), Reset input (X102)
Pulse output
settings
(Y100 to Y101)
CH0:
Normal
output
Normal output (Y100, Y101)
Pulse output (Y100, Y101)
PWM output (Y100), Normal output (Y101)
401
High-speed
counter
settings
(X200 to X202)
CHA:
Do not set
input X200 as
high-speed
counter
Do not set input X200 as high-speed counter.
Two-phase input (X200, X201)
Two-phase
input (X200, X201), Reset input (X202)
Incremental input (X200)
Incremental input (X200), Reset input (X202)
Decremental input (X202)
Decremental input (X202), Reset input (X202)
Incremental/decremental input (X200, X201)
Incremental/decremental input (X200, X201),
Reset input (X202)
Incremental/decremental control
(X200, X201)
Incremental/decremental control
(X200, X201), Reset input (X202)
CHB:
Do not set
input X201 as
high-speed
counter
Does not set input X201 as high-speed
counter.
Incremental input (X201)
Incremental input (X201), Reset input (X202)
Decremental input (X201)
Decremental input (X201), Reset input (X202)
Pulse output
settings
(Y200 to Y201)
CH1:
Normal
output
Normal output (Y200, Y201)
Pulse output (Y200, Y201)
PWM output (Y200), Normal output (Y201)
