Panasonic AFPX-C30T - Page 497

FP-X Tr type FP-X (A: Available, N/A: Not available)
Address Name Description
Read-
ing
Writ-
ing
DT90348 Elapsed
value
area
Lower words
PLS-CH0
Counting area for the pulse I/O
CH0 (Y0, Y1).
A A
Note)
DT90349 Higher words A A
Note)
DT90350
Target
value
area
Lower words
The target value is set when
instructions F171 (SPDH),
F172 (PLSH), F174 (SP0H)
and F175 (SPSH) are
executed.
A A
Note)
DT90351 Higher words A A
Note)
DT90352 Elapsed
value
area
Lower words
PLS-CH1
Counting area for the pulse I/O
CH1 (Y2, Y3).
A A
Note)
DT90353 Higher words A A
Note)
DT90354
Target
value
area
Lower words
The target value is set when
instructions F171 (SPDH),
F172 (PLSH), F174 (SP0H)
and F175 (SPSH) are
executed.
A A
Note)
DT90355 Higher words A A
Note)
DT90356 Elapsed
value
area
Lower words
PLS-CH2
Counting area for the pulse I/O
CH2 (Y4, Y5).
A A
Note)
DT90357 Higher words A A
Note)
DT90358
Target
value
area
Lower words
The target value is set when
instructions F171 (SPDH),
F172 (PLSH), F174 (SP0H)
and F175 (SPSH) are
executed.
A A
Note)
DT90359 Higher words A A
Note)
DT90360 Elapsed
value
area
Lower words
PLS-CH3
Counting area for the pulse I/O
CH3 (Y6, Y7).
A A
Note)
DT90361 Higher words A A
Note)
DT90362
Target
value
area
Lower words
The target value is set when
instructions F171 (SPDH),
F172 (PLSH), F174 (SP0H)
and F175 (SPSH) are
executed.
A A
Note)
DT90363 Higher words A A
Note)
Note) Writing in the elapsed value area is available by F1 (DMV) instruction only.
Writing in the target value area is available by F171 (SPDH), F172 (PLSH), F174 (SP0H) and
F175 (SPSH) instructions only.
