DP-2330/3030
DEC 2004
Ver. 2.0
DP-2310/3010
5 Exploded View & Parts List
Note:
1. Panasonic Document Imaging Company and other Panasonic Sales Companies reserve the right to
change any information enclosed herein without prior notification.
(This includes, but is not limited to, parts pricing, availability, and text)
2. Electrical parts supplied may include previously used components.
3. Important Safety Notice
Components identified by a mark, have special characteristics important for safety.
When replacing any of these components, use only manufacturerÌs specified parts.
4. In Remarks column, "PM" indicates ìPreventive Maintenance Part".
5. In Remarks column, "RTL" indicates that the Retention Time is limited for this item. After the
discontinuation of this assembly in production, the item will continue to be available for a specific
period of time. The retention period of availability is dependant on the type of assembly, and in
accordance with the laws governing part and product retention. After the end of this period, the
assembly will no longer be available.
6. This ìUnit" which includes other itemized parts is provided as ìLimited Availability" for your
convenience, and will only be offered for up to 3 years after the production of the unit ceases.
However, the individual contents of the assembly will be available for the standard period.
7. For Screw identification and Part Number, please refer to the last section of this chapter.
Destination Codes
Code Destination Code Destination
PA Australia; New Zealand PL Greece; Portugal
PB
England; Singapore; Malaysia; Hong
Kong
PM
Germany; Austria; Netherlands;
Belgium
PC (Canadian French kit) PP Poland; Hungary; Czech
PE
Universal 200 VAC Power Supply
Version
PR Russia; Turkey
PS Denmark; Norway; Sweden
PF France PT Taiwan
PG Italy; Switzerland PU USA; Puerto Rico; Canada
PH South Korea PX Spain; Finland
PK China PY Saudi Arabia
Destination Codes for Fax Option
Code Destination Code Destination
AA Austria
YA
Panama; Chile
(200 VAC Power Supply)
AB England
AE Taiwan
YC
Universal 200 VAC Power Supply
Version
AG Germany
AH Netherlands YG Greece
AJ Spain YK South Korea
AK Hong Kong SAR, PRC YM Malaysia
AL Australia YP Poland; Hungary; Czech
AM Switzerland YR Russia
AP Portugal YS Saudi Arabia
AR Belgium YV China
AT Turkey YW South Africa
AU USA; Puerto Rico; Canada YX Singapore
AV France
YY
Mexico; Panama
(100 VAC Power Supply)
AW New Zealand
EE Italy
EN Denmark; Finland; Norway; Sweden
