Panasonic DP-2330

198
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.18. Inverting ADF (3/3)
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
1801 DZGG000046 Motor, ADF All 1802 DZJA000695 Bracket, Gear All 1804 DZKG000113 Shaft All 1805 DZLF000331 Gear, E26S35 Drive All 1806 DZLF000283 Gear, E29 All 1807 DZLF000333 Gear, E21E27 All 1808 DZLF000335 Gear, D24E18 All 1809 DZLF000008 Gear, D16 All 1810 DZLF000191 Gear, D24 All 1811 DZJA000692 Bracket, Motor All 1812 DZLB000013 Pulley All 1814 DZLK000013 Belt, Timing All 1815 DZJA000698 Bracket, Pulley All 1816 DZKG000114 Shaft 1, Drive All 1817 DZKG000115 Shaft 2, Drive All 1819 DZLF000334 Gear, E21 Drive All 1820 DZLF000332 Gear, E18 Drive All 1830 DZJA000675 Bracket, Actuator All 1831 DZMA002329 Cover, ADF All 1832 DZKN000126 Spring, Gear All 1833 DZMG000018 Latch All 1834 DZJA000681 Bracket, Rear ADF Cover All 1835 DZJA000680 Bracket, Front ADF Cover All 1836 DZHC000102 Actuator 1 All 1837 DZKG000108 Shaft, Pinch Roller All 1838 DZLA000211 Roller, Pinch All 1839 DZKP000204 Plate Spring 2, Discharge All 1840 DZJA000677 Plate 1, Adjustment All 1841 DZHC000103 Actuator 2 All 1842 DZJM000407 Cover, Sub ADF All 1843 DZKP000200 Plate Spring, Pinch Roller All 1849 DZKP000205 Holder, Pinch Roller All 1850 DZKP000206 Plate Spring, Ground All 1851 DZJA000690
Bracket, Inverting Guide Front
All
1852 DZJA000691
Bracket, Inverting Guide Rear
All
1853 DZLA000210 Roller, Inverting Feed All 1854 DZMA002339 Cover, ADF Exit All 1855 DZGT000007 Brush, Antistatic All 1856 DZJM000424 Guide, Inverting 2 All 1857 DZJM000425 Guide, Duplex 2 All 1858 DZJM000423 Guide, Inverting 1 All 1859 DZKN000186 Spring, Duplex 2 Guide All 1860 DZJM000426 Lever, Duplex 2 Guide All 1861 DZJM000427 Guide, Upper Feed All 1862 DZJA000688 Guide, Skew All 1863 DZKG000112 Shaft, Drive Pinch All 1864 DZKP000207 Plate Spring, Drive All 1866 DZJF000409 Guide, Sub Top All 1867 DZJM000479 Film, Guide PU
1872 DZLA000207 Roller, Drive All 1873 DZJM001230 Guide, Lower Feed All 1875 DZKP000203 Plate Spring, Discharge 1 All 1876 DZJA000678 Plate, Adjustment 2 All 1877 DZKP000201 Plate Spring, Pinch 1 All 1878 DZJM000406 Guide, Inverting Feed All 1879 DZKG000110 Shaft, Pinch 2 All 1880 DZJM000476 Sponge All 1881 DZKQ000051 Spring, B1 Sensor All 1882
DZJM000496
Film, Guide A
PU
DZJM001284 Other
1884 DZJM001276 Sheet, Guide 1 All 1885 DZJM001277 Sheet, Guide 2 All 1886 DZJL000380 Plate, Heat Sink 1 All 1887 DZJM001283 Sheet, Guide B All 1888 DZJM001288 Sheet, AL All 1889 PJMDC0029Z Plate, Heat Sink 2 All 1890 DZJK000046 Clamp All
969 DZGA000017 Clutch All
1008 DZLM000109 Bushing, P3.5L5 All
