Panasonic DP-2330

224
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.23. 2nd/4th Paper Feed Module
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
2301 DZJF000418 Paper Guide 2 All 2302 DZJB000182 Base Frame All 2303 DZJE000270 Cover, Sensor All 2304 DZHC000107 Actuator 2 All 2305 DZKQ000035 Spring, Actuator All 2306 DZLA000342 Roller, Intermediate All 2307 DZMB000014 Cover, Jam Access All 2308 DZMG000015 Magnet All 2309 DZKP000084 Plate Spring, Pinch Roller All 2310 DZJA001308 Bracket, Intermediate All 2312 DZJE000821 Plate, Protection All 2313 DZJA001303 Bracket, Drive All 2316 DZMH000010 Bracket, Front All 2317 DZMH000011 Bracket, Rear All 2323 DZMC000705 Cover, Rear 2 All 2324 DZJA000723 Bracket All 2327 DZNE000101 Sheet, Fees 3 All 2333 DZHA000215 Tube, Shrink All
413 DZMC000699 Bracket, RD All 462 FFPKD07791 Bracket, Heater All 484 DZJM000511 Sheet, Protection All 485 FFPCP0035 Heater All 555 DZKN000195 Coil Spring, Arm 2 All 913 DZKK000053 Arm, Gear All 937 DZLF000342 Gear, E20 All 941 DZLF000354 Gear, E25 All 955 DZLF000430 Gear, E32B18 All 957 DZGA000037 Clutch All 972 DZLM000052 Bushing, P6L5 Conductive All
1045
DZAL000211
Photo Sensor (For DP-2330/3030) Photo Sensor (For DP-2310/3010)
All
DZAL000072 All
1101 DZJB000168 Frame, Paper Tray All 1103 DZLM000196 Collar, Feed All 1105 DZGA000038 Clutch All
1107 DZJL000350 Bracket, Ground All 1127 DZJF000622 Guide, Paper All 1128 DZJA000662 Bracket, Paper Feed All 1129 DZKK000052 Arm, Latch All 1130 DZJB000175 Base, Reverse All 1131 DZLM000106 Bushing, P6L10 All 1132 DZLG000009 Clutch, Reverse PM All 1133 DZHC000101 Actuator, NP All 1135 DZLF000322 Clutch, C30 Gear All 1136 DZLF000323 Gear, C23 Free All 1137 DZLF000448 Gear, B48 Drive All 1138 DZLF000321 Gear, B30 Drive All 1139 DZLF000320 Gear, B37 Free All 1140 DZJE001104 Guide, Rail All 1141 DZJB000368 Bracket All 1142 DZKG000360 Shaft, Feed All
1143 DZKG000365 Shaft, Reverse All 1144 DZLA000203 Roller, Paper Feed PM All 1145 DZLA000202 Roller, C25 Gear PM All 1146 DZHP008920 Assembly, Reverse Clutch PM All 1147 DZKQ000030 Spring, B All 1148 DZKQ000028 Spring, C All 1149 DZKN000389 Spring, Roller All 1150 DZLM000006 Bushing, P6L5 All 1152 FFPXA74H003C Motor, Lift DC All 1153 DZJM000440 Stopper, Paper Tray All 1155 DZKN000227 Spring 1, Ground All 1173 DZLM000103 Collar All 1627 DZLA000080 Roller, Pinch All 1913 DZEC101946 PC Board, CST2 (PbF) RTL All 1964
DZFP001681
Harness, CL2 (For DP-2330/3030)
All
DZFP001456
All
Harness, CL2 (For DP-2310/3010)
