Panasonic DP-2330

156
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.6. Process Unit (1/3)
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Note
This assembly consists of Ref. No. 625, 751, 752, 753, 841, 51 and
G6.
601 DZJM001179 Frame, Toner Cartridge All 602
DZJM001182
Cover, Toner Cartridge
PU
DZJM001207 Other
603 DZJM001184 Shutter, Hopper All 611 DZJM001178 Coupling, Hopper All 612 DZLM000195 Bearing, Rear Screw All 615 DZAN000007 Sensor, Toner All 616 DZLM000156 Bearing, Front Screw All 617
DQ-TU15E-PU
Bottle, Toner (Available as a Sales Item)
PU
DQ-TU15E-PB Other
618 DZHP008296 Container, Toner Waste All 619 DZJM001228 Sheet, Harness All 620 DZKQ000103 Spring, Harness All 621 DZNK004871 Label, HP All 622 DZJM001246 Sheet 2, Harness All 623 DZHP008929 Assembly, Hopper Box All 624 DZHP008928 Assembly, Screw All 625
DZHP008297 DZHP008297
(For DP-2330/3030) Assembly, Hopper (For DP-2310/3010) Assembly, Hopper
PU PU
DZHP008411 Other
626 DZJM001273 Sponge, Hopper All 627
DZHP009246
Developer Unit (For DP-2330/3030) (See Note) Developer Unit (For DP-2310/3010) (See Note)
PU
DZHP012132 PU DZHP009245 Other
628 DZJM001174 Sheet, Sponge All 751 DZHP008309
Assembly, Front Lock Plate (See Sect 8 Process Unit (2/3))
All
752 DZHP008310
Assembly, Rear Lock Plate (See Sect 8 Process Unit (2/3))
All
753 DZHP009247
Assembly, OPC Unit (See Sect 8 Process Unit (2/3))
All
1994
DZFP001899
Harness, Toner Empty Detector (For DP-2330/3030) Harness, Toner Empty Detector (For DP-2310/3010)
All
DZFP001443 All
19
XTB3+8JFJ
Screw (For DP-2310/3010 only) Screw All
XTB3+8J All
51
XTB3+10FFJ
Screw (For DP-2310/3010 only) Screw All
XTB3+10F
All
G6 FFPFJ0039B Snap Ring All H6 FFPFJ0033B Snap Ring All
841 DZHP008303
Assembly, Developer Unit (See Sect 9 Process Unit (3/3))
All
