Panasonic DP-2330

234
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.26. Finisher (2/6)
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
2601 PF4124K105 Assembly, Front Cover All 2602 PF4124P013 Cover, Front All 2603 PF4124P014 Lever, Front All 2604 PF4124P011 Cover, Right All 2605 PF4124K106 Assembly, Rear Cover All 2606 PF4124P015 Cover, Rear All 2607 PF4124P016 Cover, Staple All 2608 PF4124P017 Cover, Top All 2609 PF4102P256 Arm, Front All 2610 PF4102P272 Arm, Rear All 2611 PF4102K156 Assembly, Tray Guide All 2612 PF4124P040 Cover, Tray Guide All 2613 PF4104K148
Assembly, Paper Detection Solenoid
All
2614 PF4102P346 Ring All 2615 PF4102P280 Arm, Solenoid All 2616 PF4102P383 Spring, Tension All 2617 PF4104K145 Assembly, Paper Hold Lever All 2618 PF4104P925 Lever, Paper Hold All 2619 PF4102P386 Cushion, Lever All 2620 PF4102P391 Cushion, Lever All 2621 PF4102P332 Cushion, Lever All 2622 PF4102P335 Cushion, Lever All 2623 PF4124P001 Bracket, Base All 2624 PF4124K131 Bracket, Slide Roller All 2625 PF4124P029 Roller, Slide All 2626 PF4124P002 Bracket, Front Slide Guide All 2627 PF4124P003 Bracket, Rear Slide Guide All 2628 PF4124P022 Sheet, Mylar All 2629 PF4124K603 Assembly, Harness All 2630 PF4102P123 Screw All 2631 PF4124P023 Screw All 2632 PF2164P340 Screw All 2633 040060FNBI Screw All 2634 KW040FZ Washer All 2635 PF4124P033 Mylar, PCB Cover All
2636 E74382WE04SN Connector, Relay All 1045
DZAL000211
Photo Sensor (For DP-2330/3030) Photo Sensor (For DP-2310/3010)
All
DZAL000072 All
2519 PF4102P313 Cushion All 2521 PF4054P143 Screw All 2821 PF4104P837 Cushion All
