Panasonic DP-2330

232
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.25. Finisher (1/6)
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
2501 PF4102K136
Assembly, Tray Elevation Gear
All
2502 PF4102P222 Holder, Tray Elevation Gear All 2503 PF4102P315 Gear1, Tray Elevation All 2504 PF4102P288 Gear2, Tray Elevation All 2505 PF4102P289 Gear3, Tray Elevation All 2506 PF4102P223 Holder, Tray Elevation Gear All 2507 PF4102P224 Holder, Base All 2508 PF4102K215 Harness, Tray All 2509 PF4102P277 Cover, Base All 2510 PF4102P293 Lever, Base All 2511 PF4102P512 Motor, Tray Elevation All 2512 PF4102P294 Cover, Motor All 2513 PF4102P227 Holder, Tray All 2514 PF4102P281 Plate, Tray All 2515 PF4124K107 Assembly, Tray All 2516 PF4124P020 Tray, Sub All 2517 PF4124P019 Tray, Middle All 2518 PF4124P018 Tray, Main All 2519 PF4102P313 Cushion All 2520 PF2252P619 Snap Ring All 2521 PF4054P143 Screw All 2522 PF4124K127 Assembly, Finisher Tray All 1045
DZAL000211
Photo Sensor (For DP-2330/3030) Photo Sensor (For DP-2310/3010)
All
DZAL000072 All
