Panasonic DP-2330

240
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.29. Finisher (5/6)
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
2733 E450001146 Clamp, Harness All 2735 ER050SKP E-Ring All 2736 030060FZWS Screw All 2849 PF2225P312A Bushing All 2850 PF4102P237A Bushing All
2901 PF4102K133 Assembly, Upper Guide All 2902 PF4102P213 Guide, Upper All 2903 PF4102P334 Sheet, Mylar All 2904 PF4102P337 Sheet, Mylar All 2905 PF4104P930 Holder, Paper Guide All 2906 PF4104K153 Assembly, Paper Guide All 2907 PF4102P266 Guide1, Paper All 2908 PF4104P845 Sheet, Mylar All 2909 PF4102P265 Guide2, Paper All 2910 PF4102P037 Bracket, Feed Roller All 2911 PF4102K177 Assembly, Feed Roller All 2912 PF4102P379 Roller, Feed All 2913 PF4102K175 Assembly, Feed Arm All 2914 PF4102P378 Holder, Feed Arm All 2915 PF4102P305 Belt, Feed Arm All 2916 PF4102P270 Roller, Feed Arm All 2917 PF4102P116 Weight, Feed Arm All 2918 PF4102P269 Holder, Feed Arm All 2919 PF4102P231 Bushing All 2920 PF4102P405 Tray, Staple Guide All 2921 PF4102P406 Guide, Paper All 2922 PF4102P398 Sheet, Mylar All 2923 PF4102K159 Assembly, Exit Actuator All 2924 PF4102P209 Actuator, Exit All 2925 PF4102P367 Cushion, Exit Actuator All 2926 PF4102P327 Spring, Tension All 2927 PF4102P005 Plate, Rack All 2928 PF4102K107 Assembly, Rack Gear All 2929 PF4102P206 Gear, Rack All 2930 PF4102P207 Guide, Set All 2931 PF4102K221 Motor, Set All 2932 PF4102P036 Bracket, Set Motor All 2933 PF4102K213 Harness, Paper Exit Sensor All 2934 PF4111K256 Ground All 2935 PF4102P351 Cushion, Paper Guide All 2936 PF4102K109 Assembly, Exit Roller All
2937 PF4102P307 Roller, Exit All 2938 PF4124P600 Staple Unit All 2939 PF4102P040 Bracket, Staple Unit All 2940 E450001148 Clamp, Harness All 2941 PF4102K158 Staple Safety Switch All 2942 030060FZTP Screw All 2943 023120FZWS Screw All 2944 PF4102K211 Harness, SW All 1045
DZAL000211
Photo Sensor (For DP-2330/3030) Photo Sensor (For DP-2310/3010)
All
DZAL000072 All
2521 PF4054P143 Screw All 2629 PF4124K603 Assembly, Harness All 2632 PF2164P340 Screw All 2633 040060FNBI Screw All
