Panasonic DP-2330

158
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.7. Process Unit (2/3)
742 DZHP004158 Star Wheel All 743
DZPA000094
Screw, Process Unit (For DP-2310/3010 only) Screw, Process Unit All
DZPA000088 All
744 DZPG000001 Pin All 745 DZPK000027 Washer, Set All 746 DZHC000163 Sheet, Shield All 747 DZJM001238 Sponge1, Cleaning Blade All 748 DZJM001239 Sponge2, Cleaning Blade All 750 DZHP006512 Assembly, Paddle All 751 DZHP008309 Assembly, Front Lock Plate All 752 DZHP008310 Assembly, Rear Lock Plate All 753 DZHP009247 Assembly, OPC Unit All
19
XTB3+8JFJ
Screw (For DP-2310/3010 only)
All
XTB3+8J
All
20
XTB3+8FFJ
Screw (For DP-2310/3010 only)
All
XTB3+8F All
23
XYN3+F8FJ
Screw (For DP-2310/3010 only)
All
XYN3+F8 All
51
XTB3+10FFJ
Screw (For DP-2310/3010 only)
Screw
Screw Screw Screw
All
XTB3+10F All
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
701 DZJM001197 Frame, OPC All 702 DZJM001198 Arm, Front DSD All 703 DZLM000198 Arm, Rear DSD All 704 DZJN000082 Blade, Cleaning PM All 705 DZJL000360 Plate, Cleaning Roller All 706 DZLA000349 Roller, Cleaning PM All 707 DZLM000199 Bearing, Front Cleaning All 708 DZJM000371 Pipe, Toner Waste All 709 DZJL000361 Shaft, OPC Drum All 710 DZJM001199 Sheet, Scoop PM All 712 DZKP000352 Plate, Charge All 713 DZLM000200 Bearing, Rear Cleaning All 716 DQ-H060E-PU
Drum, OPC (Available as a Sales Item)
PM
All
717 DZJP000060 Felt, Front Cleaning PM All 718 DZJP000061 Felt, Rear Cleaning PM All 720 DZJM001203 Sponge, Cleaning PM All 721 DZLM000201 Bushing, Screw All 722 DZLN000020 Joint, Screw All 723 DZJL000362 Plate, Nut All 724 DZHD000028 Sheet, Radiation All 725
DZLA000129
Roller, Bias Charge (For DP-2310/3010) Roller, Bias Charge (For DP-2330/3030)
PM
All
DZLA000386
PM
726 DZLM000049 Bushing, Bias Charge Roller All 727 DZKN000080 Coil Spring, Bushing All 728 DZJC000298 Holder, Bias Charge Roller All 731 DZJM001240 Shaft, Screw All 732 DZLM000097 Holder, OPC Drum Shaft All 733 DZLN000004 Joint, Paddle All 734 DZJM000372 Cap, WTB All 735 DZKN000178 Coil Spring, Cap All 741 DZKP000225 Plate, Star Wheel All 738 DZJM000376 Sponge, Paddle All 739 DZJM000377 Sponge, Cap All 740 DZJM000378 Sponge, Pipe All
