Panasonic DP-2330

162
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.9. Drive Unit
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
901
DZHP008360
Assembly, Main Drive (For DP-2310/3010) (See Note)
All
DZHP010693
Assembly, Main Drive (For DP-2330/3030) (See Note)
All
902 DZLF000337 Gear, D52E13 All 903 DZLF000338 Gear, D60E30 All 904 DZLF000339 Gear, E34 All 905 DZLF000340 Gear, E32 All 906
DZHP008362
Ass (For DP-2310/3010)
embly, OPC Drive
All
DZHP010694
Ass (For DP-2330/3030)
embly, OPC Drive
All
907 DNQ16D34R44A Motor, Main All 908 DZJA001304 Bracket, Motor All 909 DZJA001305 Bracket, Gear All 910 DZLF000345 Gear, E23 All 911 DZJA001306 Bracket, 1st Tray Drive Sub All 912 DZLF000344 Gear, E42B21 All 914 DZLM000143 Bearing All 919 DZLM000167 Bushing All 920 DZKG000362 Shaft, OPC Drive All 921 DZLF000659 Gear, E24B All 922 DZLL000004 Wheel, Fly All 923 DZLF000660 Gear, D36 All 924 DZPG000012 Pin All 925 DZLF000665 Gear, C60 All 926 DZKN000386 Coil Spring, OPC All 927 DZLN000007 Joint, OPC All 928 DZKN000190 Coil Spring, Development All 929 DZLF000347 Gear, B39 All 930 DZLF000661 Gear, D26B All 931 DZLF000351 Gear, B22 All 932 DZLF000349 Gear, B42B21 All 933 DZLF000350 Gear, B40 All 934 DZLF000352 Gear, B32 All
942 DZLF000664 Gear, E28E16 All 943 DZLF000666 Gear, B23 All 944 DZLF000667 Gear, D30E13 All 945 DZLF000668 Gear, E32E15 All 946 DZLF000669 Gear, D26E13 All 947 DZLF000670 Gear, C22 All 948 DZLF000671 Gear, B39 All 949 DZKG000361 Shaft, TYK/PDC All 950 DZGA000009 Clutch, OPC All 951 DZKN000257 Spring, FU All 952
DZPA000065 or Screw All XX4W5FP-B Screw All
953 DZJH000083 Washer All 954 DZLF000437 Gear, E24A All 955 DZLF000430 Gear, E32B18 All
956 DZJC000339 Holder, Clutch All 957 DZGA000037 Clutch All 958 DZHP008363 Assembly, Toner Motor All 960 DZLF000433 Gear, B30 All 961 DZLF000518 Gear, B58 All 962 DZLF000517 Gear, B20 All 963 DZKN000388 Spring, BTL All 964 DZJM000794 Collar All 965 DZLF000441 Gear, B58B14 All 966 DZJA001329 Bracket, Sensor All 967 DZLF000443 Gear, B62B15 All 968 DZLF000600 Gear, B78 All 970 DZKG000358 Shaft, Clutch All 971 DZLF000361 Gear, E18 All 972 DZLM000052 Bushing, P6L5 Conductive All 973 DZLF000325 Gear, B27 All
936 DZLF000355 Gear, E29 All 937 DZLF000342 Gear, E20 All
938 DZKN000206 Spacer, Gear All 939 DZJA001302 Bracket, 1st Tray Drive All 940 DZLF000663 Gear, B41 All
