Panasonic DP-2330

274
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
6 Alphanumerical Parts List
Alphanumerical Parts List
Part Number Part Name Ref. No. PM Destination
023120FZWS Screw 2943 All
030060FZTP Screw 2942 All
030060FZWS Screw 2736 All
040040FNBI Screw 3030 All
040060FNBI Screw 2633 All
55SPM25D7ND1 Motor, Transport 1320 All
AM59259-A Micro Switch 461 All
B3X6TTS-RP Screw (For DP-2310/3010 only) P1 All
CR2032 Battery 119 All
DA-AR250-PB
Inverting ADF Unit (For DP-2310/3010) 1668
Other
DA-AR250-PK PH, PK, PT
DA-AR251-PB
Inverting ADF Unit (For DP-2330/3030) 1668
Other
DA-AR251-PK PH, PK, PT
DA-AS200-PB
ADF Unit (For DP-2310/3010) 3102
Except PU, PH, PK, PT
DA-AS200-PK PH, PK, PT
DA-AS201-PB
ADF Unit (For DP-2330/3030) 3102
Except PU, PH, PK, PT
DA-AS201-PK PH, PK, PT
DNQ16D34R44A Motor, Main 907 All
DZAL000003 Sensor 270 All
DZAL000072 Photo Sensor (For DP-2310/3010)
1045
All
DZAL000211 Photo Sensor (For DP-2330/3030) All
DZAN000006 Sensor, TDC 838 All
DZAN000007 Sensor, Toner 615 All
DZBL000043 PC Board, HSU 1974 All
DZBL000056 Thermistor Assembly 1041 PM All
DZCC000006 Switch, Power 486 All
DZDA000041 LCD Module 128 All
DZDG000077 Choke Coil 2 314 Except PU, PT
DZDG000124 Choke Coil 1 313 Except PU, PT
DZDN000105 Ferrite Core 131 Except PU
DZDX000003 Thermostat 1038 All
DZDX000018 Fuse, Thermal 1040 All
DZEA000070 PC Board, Inverter 129 All
DZEA000080
LVPS 1910
PU, PT
DZEA000081 Other
DZEA000082 PC Board, Inverter 268 All
DZEC101608 PC Board, EXFD 1978 All
DZEC101648 PC Board, ADF (i-ADF) 1907 All
DZEC101946 PC Board, CST2 1913 All
DZEC102122 PC Board, PNL3 113 All
DZEC102128 PC Board, ACD 1904 PU, PT
DZEC102137 PC Board, FRM 8 (For DP-2310/3010) 1972 All
DZEC102175 PC Board, DC 1905 All
DZEC102176 PC Board, DCB 1906 All
DZEC102274 PC Board, PNL4 114 All
DZEC102302 PC Board, LFB 1969 All
DZEC102303 PC Board, ADF (ADF) 1907 All
DZEC102304 PC Board, SNS 1981 All
DZEC102345 PC Board, FXB (For DP-2310/3010) 1916 PU
