Panasonic DP-2330

194
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.17. Inverting ADF (2/3)
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
1701 DZLM000007 Bushing, P6L7.4 All 1702 DZKG000122 Shaft, P8L All 1705 DZKG000123 Shaft, P8S All 1706 DZJM000434
Holder, Spring T (Shallow Groove)
All
1707 DZJM000435
Holder, Spring B (Deep Groove)
All
1711 DZJA000694 Plate, Reinforcement B All 1712 DZJA000693 Plate, Reinforcement A All 1714 DZLF000382 Gear, E18 All 1716 DZLF000036 Gear, E25 All 1718 DZLF000028 Gear, E14E28 All 1719 DZJA000683 Bracket, Rear ADF All 1722 DZKM000020 Sheet, ADF All 1723 DZJF000407 Guide, Upper ADF All 1724 DZKG000109 Shaft, ADF All 1725 DZJM000411 Guide, Rear ADF All 1726 DZJM000410 Guide, Front ADF All 1727 DZJM000408 Holder, ADF All 1728 DZLA000205 Roller, ADF PM All 1729 DZLF000329 Gear, ADF All 1730 DZKG000107 Shaft, Pre-Feed Roller All 1731 DZLA000204 Roller, Pre-Feed PM All 1732 DZLF000330 Gear, Pre-Feed Roller All 1733 DZLF000385 Gear, D16 All 1734 DZKP000202 Plate Spring, Pinch Roller All 1735 DZJA000676 Plate, Release Lever All 1736 DZJF000408 Guide, Lower ADF All 1737 DZJM000409 Stopper, Original All 1738 DZKG000111 Shaft, Separation Roller All 1739 DZJM000415 Bushing All 1740 DZLA000206 Roller, Separation PM All 1741 DZJM000416 Bushing, Torque Limiter PM All 1742 DZKQ000031 Spring, Torque Limiter PM All 1746 DZJM000414 Gear, Pre-Feed Roller All 1747 DZKN000184 Spring, Separation Roller All
1748 DZJM000413 Holder, Separation Roller All 1749 DZJM000442 Film, ADF Pre-Feed All 1750 DZKN000209 Spring, Latch All 1751 DZLA000209 Roller, Exit All 1752 DZJM000420 Guide, Reversing 1 All 1753 DZLA000208 Roller, Feed 2 All 1754 DZJM000418 Guide, Feed 2 Roller All 1755 DZJM000419 Holder, Sensor C All 1756 DZHC000105 Actuator, Sensor C All 1757 DZJA000684 Holder, Sensor B2 All 1758 DZKR000024 Spring, Sensor B2 All 1759 DZHC000104 Actuator, Sensor B2 All 1760 DZJA000682 Bracket, Front ADF All 1761 DZJA000679 Bracket, Solenoid All 1762 DZGB000023 Solenoid All
1763 DZJM000412 Release Lever All 1764 DZJM000432 Cover, Gear Bracket All 1765 DZLF000015 Gear, B44 All 1766 DZKN000006 Coil Spring, Idle Gear All 1767 DZJM000431 Plate, Moving Gear All 1768 DZJA000697 Bracket, Moving Gear All 1769 DZLF000172 Gear, B42E27 All 1770 DZGB000024 Solenoid All 1771 DZKN000185 Spring, Reversing Guide 1 All 1772 DZJA000685 Bracket, Reversing Guide 1 All 1773 DZJM000422 Adjuster All 1774 DZJM000421 Joint All 1775 DZJA000686 Bracket, Reversing Guide 2 All 1776 DZKN000188 Spring All 1777 DZFC000231 Connector 2 All 1778 DZFC000232 Connector 3 All 1779 DZLF000327 Gear, B18 All 1780 DZJM000430 Lever, Stopper All 1782 DZKN000231 Spring, Hinge Support All 1783 DZJM000477 Stopper, Rubber All 1784 DZKQ000042 Spring, Introduction All
