Panasonic DP-2330

186
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.14. Automatics Duplex Unit
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
1401 DZJE000774 Guide, Transport All 1402 DZHC000112 Actuator, A All 1403 DZHC000111 Actuator, B All 1404 DZJE000773 Guide, Duplex All 1405 DZJF000623 Frame, Duplex All 1407 DZJA000717 Bracket, Gear All 1408 DZJA001299 Bracket 2, Gear All 1409 DZLA000340 Roller, Drive All 1410 DZLA000341 Roller 2, Drive All 1411 DZKN000200 Spring, Pinch All 1412 DZKQ000038 Spring, Gear All 1413 DZJA001307 Bracket, Duplex All 1414 DZKQ000041 Spring, Actuator 2 All 1416 DZLF000674 Gear, E20E15 All 1417 DZPK000017 Washer, Polyethylene All 1419 DZLF000435 Gear, E32 All 1420 DZNE000103 Myler, Guide All 1422 DZHA000216 Tube, Shrink All
936 DZLF000355 Gear, E29 All 937 DZLF000342 Gear, E20 All 941 DZLF000354 Gear, E25 All 957 DZGA000037 Clutch All 972 DZLM000052 Bushing, P6L5 Conductive All
1045
DZAL000211
Photo Sensor (For DP-2330/3030)
All
DZAL000072 All
1150 DZLM000006 Bushing, P6L5 All 1313 DZKG000121 Shaft, Roller All 1316 DZKN000202 Spring, Actuator All 1513 DZKN000197 Spring, Roller All 1518 DZLA000229 Roller, Pinch All 1820 DZLF000332 Gear, E18 Drive All 1993
DZFP001736
Harness, DUX (For DP-2330/3030) Photo Sensor (For DP-2310/3010) Harness, DUX (For DP-2310/3010)
All
DZFP001419 All
3209 DZPK000019 Slider All
19
XTB3+8JFJ Screw
Screw (For DP-2310/3010 only)
All
XTB3+8J All
S9 DZJM000171 Snap Ring All
