Panasonic DP-2330

140
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.2. Scanner Unit
201 DZGG000054 Motor, Scanning All 202 DZLK000011 Belt, Inner Timing All 203 DZLK000012 Belt, Outer Timing All 204 DZGM000010 Lamp, Scanning All 206 DZKP000141 Plate Spring, Mirror 2 All 207
DZHP DZHP010590
008365
Assembly, CCD (For DP-2330/3030) Assembly, CCD (For DP-2310/3010)
PU PU
DZHP008971 Other
208 DZLK000021 Belt, Synchro All 209 DZJB000130 Base, Front Lamp All 210 DZJB000131 Base, Rear Lamp All 211 DZJM000361 Slider PM All 212 DZJE000734 Cover, Inverter Upper All 213 DZJE000735 Cover, Inverter Lower All 214 DZJB000132 Base, Mirror 2 All 215 DZJC000251 Holder A, FPC Cable All 216 DZJC000252 Holder B, FPC Cable All 217 DZLB000026 Pulley, MXL34 All 219 DZLB000023 Pulley L All 221 DZLM000095 Bushing, P6 All 223 DZLB000022 Pulley S All 224 DZJA000641 Bracket, Lamp Base All 225 DZJL000097 Belt Lock, Front Lamp All 226 DZJL000098 Belt Lock, Rear Lamp All 227 DZJL000099 Belt Lock, Front Lamp All 228 DZJL000100 Belt Lock, Rear Lamp All 229 DZJA000642 Bracket, Adjustment All 230 DZKP000187 Plate Spring, Mirror All 231 DZNC000006 Plate, Reflection All 232 DZKP000190 Plate Spring, Lamp All 233 DZJA000643 Bracket, Mirror 2 All 234 DZJL000101 Clamp, Front Mirror All 235 DZJL000102 Clamp, Rear Mirror All 236 DZJL000103 Belt Lock, Front Mirror All 237 DZJL000104 Plate, Lock Adjustment All
Ref.
No.
Part Number Part Name
PM/
RTL
Destination
240 DZJL000106 Frame, F/R Scanner All 241 DZJL000107 Frame, Left Scanner All 242 DZJL000108 Frame, Right Scanner All 243 DZJL000109 Rail, Rear Scanner All 244 DZJL000110 Rail, Front Scanner All 245 DZJB000135 Base, Size Sensor All 246 DZJA000644 Bracket, INS Sensor All 247 DZJA000645 Plate, Scanner Locking All 248 DZLB000024 Pulley, Idler All 249 DZJA000647 Bracket, Motor All 250 DZJA000648 Bracket, Pulley All 251 DZJM000500 Covering Film, SNS All 252 DZJA000741 Plate Spring, Mirror 1 All 254 DZJM000362 Carriage Sheet All
Ref.
No.
Part Number Part Name
PM/
RTL
Destination
255 DZKN000176 Coil Spring, Pulley All 258 DZKN000177 Coil Spring, Adjustment All 259 DZHA000138
Insulation Sheet A, FPC Cable
All
260 DZFR000032
Cable, FPC (Flex Print Cable)
All
261 DZHA000145
Insulation Sheet B, FPC Cable
All
262 DZHA000146
Insulation Sheet C, FPC Cable
All
263 DZJM000445 Sheet, Damper All 264
DZTC000039 or
Mirror 1 All
DZTC000057
265
DZTC000040 or
Mirror 2 All
DZTC000058
267 DZNK002793 Caution Label, FPC All 268 DZEA000082 PC Board, Inverter All 269 DZHP004387 Sensor 3, Size All 270 DZAL000003 Sensor All 272 DZJC000287 Bracket, Dehumidifier All 273 DZFR000013 Thermistor All
238 DZJL000105 Belt Lock, Rear Mirror All 239 DZJB000134 Frame, Scanner Base All
