Panasonic DP-2330

238
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.28. Finisher (4/6)
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
2851 PF4102K212 Harness, Top Cover Sensor All 1045
DZAL000211
Photo Sensor (For DP-2330/3030) Photo Sensor (For DP-2310/3010)
All
DZAL000072
All
2521 PF4054P143 Screw All 2633 040060FNBI Screw All 2732 PF4102P387 Cushion, Lever All 2734 PF2252P620 Snap Ring All
2801 PF4102P234 Base, Guide All 2802 PF4102P028 Plate, Front Ground All 2803 PF4102P029 Plate, Rear Ground All 2804 PF4104K143 Assembly, Exit Guide All 2805 PF4102P248 Shaft, Exit Guide All 2806 PF4102P316 Arm, Exit Guide All 2807 PF4104P929 Holder, Exit Guide Arm All 2808 PF4102P319 Sheet, Mylar All 2809 PF4090P446 Belt, Exit Guide All 2810 PF4102P260 Bushing All 2811 PF4102P112 Shaft, Exit Guide All 2812 PF4102P249 Gear, Exit Guide All 2813 PF4102P250 Holder, Shaft All 2814 PF4102P111 Shaft, Paper Hold All 2815 PF4104K144 Assembly, Paper Hold Lever All 2816 PF4104P928 Lever, Paper Hold All 2817 PF4104P834 Stopper, Rubber All 2818 PF4102P235 Roller, Paper Hold All 2819 PF4104K147 Assembly, Lower Guide All 2820 PF4102P304 Frame, Lower Guide All 2821 PF4104P837 Cushion, Lower Guide Frame All 2822 PF4104P841 Sheet, Mylar All 2823 PF4104P842 Sheet, Mylar All 2824 PF4102P325 Brush, Exit Guide All 2825 PF4102P317 Brush, Exit Guide All 2826 PF4102P038 Bracket, Guide Base All 2827 PF4102P301 Spring, Tension All 2828 PF4102P302 Spring, Tension All 2829 PF4102P262 Bushing All 2830 PF2166P034 Snap Ring All 2831 PF4102P324 Bushing All 2832 PF4102P369 Base, Guide All 2833 PF4102K138
Assembly, Paper Detection Lever
All
2834 PF4102P255 Lever, Paper Detection All 2835 PF4102P303 Spring, Tension All
2836 PF4104P846 Spring, Tension All 2837 PF4102K115 Assembly, Paper Hold Roller All 2838 PF4102P215 Holder, Paper Hold Roller All 2839 PF4102P258 Roller, Paper Hold All 2840 PF4102K116 Assembly, Paper Hold Roller2 All 2841 PF4102P275 Roller2, Paper Hold All 2842 PF4104P844 Sheet, Mylar All 2843 PF4102P333 Sheet, Mylar All 2844 PF4104K141 Assembly, Paper Hold Lever All 2845 PF4104P927 Lever, Paper Hold All 2846 PF4102P357 Sheet, Mylar All 2847 PF4104K149 Assembly, Paper Hold Lever2 All 2848 PF4104P840 Sheet, Mylar All 2849 PF2225P312 Bushing All 2850 PF4102P237 Bushing All
