Panasonic DP-2330

188
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.15. Dual-Path Exit Guide Unit
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
1501 DZJF000426 Guide, Paper Exit A All 1502 DZJF000427 Guide, Paper Exit B All 1503 DZHC000110 Actuator, Paper Exit All 1504 DZKK000059 Arm, Solenoid All 1505 DZLF000679 Gear, E25 All 1506 DZJB000184 Bracket, Front All 1507 DZJB000185 Bracket, Rear All 1508 DZMH000012 Bracket, Solenoid All 1509 DZKP000214 Plate Spring, Idle Roller All 1510 DZLA000219 Roller, Feed All 1511 DZLA000217 Roller, Idle All 1512 DZKN000198 Spring, Guide All 1513 DZKN000197 Spring, Roller All 1514 DZKQ000037 Spring, Exit Actuator All 1515 DZGT000040 Brush, Discharge All 1516 DZGB000025 Solenoid All 1518 DZLA000229 Roller, Pinch All 1521 DZMC000702 Cover, Exit All 1522
DZML000509
Tray, Inner (For DP-2330/3030)
All
DZML000339 All
1524 DZJM000473 Holder, Paper All 1525 DZJE001114 Cover, Harness All 1526 DZKL000082 Spacer All 1528
DZHP008351
Dual-Path Exit Guide Unit
All
1529 DZNE000108 Sheet, Guide All 1530 DZHD000034 Sheet, Rear Bracket All 1531 DZJM001275 Sheet, Top Sensor All
937 DZLF000342 Gear, E20 All
1008 DZLM000109 Bushing, P3.5L5 All 1009 DZLM000110 Bushing, P3.5L5 All 1012 DZLF000356 Gear, E41 Free All 1013 DZLF000357 Gear, E18 Drive All
Tray, Inner (For DP-2310/3010)
1045
DZAL000211
Photo Sensor (For DP-2330/3030) Photo Sensor (For DP-2310/3010)
All
DZAL000072 All
1313 DZKG000121 Shaft, Roller All 1316 DZKN000202 Spring, Actuator All 1403 DZHC000111 Actuator, B All 1406 DZJF000632 Guide, Top Duplex All 1411 DZKN000200 Spring, Pinch All 1418 DZNK002923 Label, High Temperature All 1984
DZFP001737
Harness, 2WAY (For DP-2330/3030) Harness, 2WAY (For DP-2310/3010)
All
DZFP001421 All
19
XTB3+8JFJ Screw All XTB3+8J All
36
XYN3+F6FJ Screw All XYN3+F6 All
6P
XTW3+6LFJ
Screw Screw (For DP-2310/3010 only)
(For DP-2310/3010)
DZML000509
Dual-Path Exit Guide Unit
All
(For DP-2330/3030)
Screw (For DP-2310/3010 only) Screw (For DP-2310/3010 only)
All
XTW3+6LFC All
S9 DZJM000171 Snap Ring All
