Panasonic DP-2330

17
DP-2330/3030
DEC 2004
Ver. 2.0
DP-2310/3010
1.2. Fax, Printer and Internet Fax Functions
1.2.1. Fax Function
Items
Description
Remarks
DP-2310/2330 DP-3010/3030
Main Specifications
1 Compatibility G3 ITU-T Std & Non-Std
2 PSTN Line Port Yes 1-Line Only
3 Leased Line Port No
4 V.24 Line Port No
5 Modem Speed 33.6 - 2.4kbps T.30/V.34/V.17/V.29/V.27ter
6 Coding Scheme JBIG/MMR/MR/MH
7 ECM Yes Conforms to ITU-T Rec. T.30 ECM
8 Short Protocol Yes (B, D)
9 Transmission Speed
Approx. 3 sec.
ITU-T Image No. 1
(A4, Std Resolution)
10
Communication Resolution
dpi x lpi (pels/mm x lines/
mm)
Transmission
Std. 203 x 98 (8 x 3.85)
Fine 203 x 196 (8 x 7.7)
S-Fine 203 x 391 (8 x 15.4)
406 x 391 (16 x 15.4)
600dpi 600 x 600 dpi
Reception
Std. 203 x 98 (8 x 3.85)
Fine 203 x 196 (8 x 7.7)
S-Fine 203 x 391 (8 x 15.4)
406 x 391 (16 x 15.4)
600dpi 600 x 600 dpi
600 dpi communication is only
available between WORKiO DP-2310/
3010/3510/4510/6010 and other T.30
compliant machines.
Scanner Mechanism
1 Scanning Device CCD (ADF / Platen)
2 Scanning Speed (ADF)
Resolution Vertical Horizontal
A4, Scanned in Vertical or Horizontal
Direction.
Excluding Initializing Time and ADF
slipping factor.
Std: 203 x 98 (8 x 3.85)
dpi x lpi (pels/mm x lines/
mm)
0.6 sec. 0.4 sec.
Fine: 203 x 196 (8 x 7.7)
dpi x lpi (pels/mm x lines/
mm)
S-Fine: 406 x 391 (16 x
15.4) dpi x lpi (pels/mm x
lines/mm)
1.1 sec. 0.8 sec.
600dpi: 600 x 600
1.7 sec. 1.2 sec.
Scanning Speed (Platen)
Resolution Vertical Horizontal
600dpi: 600 x 600
1.7 sec. 1.2 sec.
3
Scanning Resolution
dpi x lpi (pel/mm x lines/
mm)
Std 203 x 98 (8 x 3.85)
Fine 203 x 196 (8 x 7.7)
S-Fine 203 x 391 (8 x 15.4)
406 x 391 (16 x 15.4)
600dpi 600 x 600 dpi
4 Document Size (Max.) ADF: Ledger / A3
