5.38. Hard Disk Drive Unit
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
3801 DZRB000750 Assembly, HDD Cushion All 3802 DZSM000696 Installation Instruction All 3803 DZHP008927 Assembly, HDD Holder All 3804 DZJK000067 Clamp, Harness All 3805 DZJK000068 Clamp, Harness PU 3806 DZJK000077 Clamp, Harness Except PU 3807 DZJK000059 Clamp, Harness Except PU
304 DZHL000002 HDD All
1906 DZEC102176 PC Board, DCB (PbF) RTL All 1942
DZFP001499
Harness, HD
PU
DZFP001526 Other
1949 DZFP001687
Harness, DC12
All
1949 DZFP001468 All 1960 DZFP001467
Harness, HDD2
All
1960 DZFP001746 All 3701 DZRB000733 Carton Box All
23
XYN3+F8FJ Screw All XYN3+F8 All
6P
XTW3+6LFJ
Screw
Screw (For DP-2310/3010 only)
Screw (For DP-2310/3010 only)
All
XTW3+6LFC All
P7 FFPFA0152 Screw All
