Panasonic DP-2330

166
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.10. Fuser Unit
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
1001 DZJM001191 Guide, Upper All 1002 DZJE001212 Cover, Upper Fuser All 1003 DZJE001106 Cover, Lower Fuser All 1004 DZJB000371 Guide, Harness All 1005 DZHC000106 Actuator, Paper Exit All 1006 FFPJF0034 Bushing, Insulation All 1007 DZJF000625 Guide, Turn All 1008 DZLM000109 Bushing P3.5L5 All 1009 DZLM000110 Bushing P3.5L5 All 1012 DZLF000356 Gear, E41 Free All 1013 DZLF000357 Gear, E18 Drive All 1014 DZLF000558 Gear, Fuser Roller All 1015 DZKK000114 Arm, Front Pressure All 1016 DZKK000115 Arm, Rear Pressure All 1017 DZJE001111 Frame, Fuser All 1018 DZJC000357 Holder, Front Lamp All 1019 DZJF000626 Guide, Paper All 1020 DZKP000327 Spring Idle Roller All 1021 DZJC000358 Holder, Rear Lamp All 1022 DZJE001112 Cover, Strap All 1023 DZJL000355 Plate, Spacer All 1024 DZJE001108 Cover, Front Lamp All 1025 DZJE001109 Cover, Rear Lamp All 1026 DZLA000372 Roller, Fuser PM All 1027 DZLA000373 Roller, Pressure PM All 1028 DZLA000347 Roller, Exit All 1029 DZKN000390 Spring, Pressure All 1031 DZJL000358 Plate, Sensor All 1033 DZPA000025 Screw, Shoulder All 1034 DZKQ000033 Spring, Jam Cover All 1035 DZKQ000032 Spring, Exit Actuator All 1036 DZKA000030 Band, Jam Cover All 1037 DZNK003616 Label, High Temperature All 1038 DZDX000003 Thermostat (See Note) All 1039 DZLM000112 Bearing PM All
1040 DZDX000018 Fuse, Thermal (See Note) All 1041 DZBL000056 Thermistor Assembly PM All 1043
DZGN000042 Lamp, Fuser (450W, 100V)
PM
PU, PT
DZGN000044 Lamp, Fuser (450W, 200V) Other
1044
DZGN000049 Lamp, Fuser (600W, 100V)
PM
PU, PT
DZGN000050 Lamp, Fuser (600W, 200V) Other
1045
DZAL000211
Photo Sensor (For DP-2330/3030) Photo Sensor (For DP-2310/3010)
All
DZAL000072 All
1046 DZLM000168 Bearing, Fuser Roller PM All 1049 DZLA000327 Roller, Idle All 1050 DZJL000376 Terminal, Fuser Lamp All 1052 XWG55E12FY Washer All 1054 DZHD000027 Plate, Shield All 1055 DZJL000351 Bracket, Frame All 1056 DZJC000360 Holder, Rear Roller All
1057 DZJC000359 Holder, Front Roller All 1058 DZKG000363 Shaft, Pinch All 1059 DZLA000344 Pinch Roller All 1060 DZJL000352 Plate A, Terminal All 1061 DZJL000353 Plate B, Terminal All 1062 DZJL000354 Plate C, Terminal All 1063 DZHC000162 Actuator, Intermediate All 1067 DZJM001261 Finger, Upper PM All 1068 DZKG000351 Shaft, Pinch All 1069 DZJL000356 Plate, Stopper All 1070 DZJM001193 Bracket 1, Front Web All 1071 DZJM001194 Bracket, Rear Web All 1072 DZJE001113 Cover, Web All 1073 DZJM001195 Bracket 2, Front Web All 1074 DZKK000116 Arm, Web All 1075 DZLF000676 Gear, Web Drive All 1076 DZLF000677 Gear, Warm Web All 1077 DZJM001196 Gear, Stopper Web All 1078 DZPJ000004 C-Ring All
