Panasonic DP-2330

228
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.24. 3rd Paper Feed Module
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
1173 DZLM000103 Collar All 1627 DZLA000080 Roller, Pinch All 1914 DZEC102749 PC Board, CST3 (PbF) RTL All 1965
DZFP001689
Harness, SNS (For DP-2330/3030)
All
DZFP001497 All
1966
DZFP001717
Harness, Paper Tray Sensor (For DP-2330/3030)
All
DZFP000863 All
1968
DZFP001677
Harness, OQM (For DP-2330/3030)
All
DZFP001447 All
1988
DZFP001702
Harness, CL3 (For DP-2330/3030)
All
DZFP001530 All
Harness, SNS (For DP-2310/3010) Harness, Paper Tray Sensor (For DP-2310/3010) Harness, OQM (For DP-2310/3010) Harness, CL3 (For DP-2310/3010)
2401 DZJA001328 Plate, Protection All 2402 DZGG000072 Motor, Drive All 2403 DZJA001300 Bracket 1, Drive All 2404 DZJA001301 Bracket 2, Drive All 2405 DZLF000673 Gear, E26 All 2406 DZLF000658 Gear, B50E18 All 2407 DZJC000338 Holder, Clutch All
413 DZMC000699 Bracket, RD All 462 FFPKD07791 Bracket, Heater All 484 DZJM000511 Sheet, Protection All 485 FFPCP0035 Heater All 936 DZLF000355 Gear, E29 All 938 DZKN000206 Spacer, Gear All 955 DZLF000430 Gear, E32B18 All 957 DZGA000037 Clutch All 971 DZLF000361 Gear, E18 All 972 DZLM000052 Bushing, P6L5 Conductive All
1045
DZAL000211
Photo Sensor (For DP-2330/3030) Photo Sensor (For DP-2310/3010)
All
DZAL000072 All
1101 DZJB000168 Frame, Paper Tray All 1103 DZLM000196 Collar, Feed All 1105 DZGA000038 Clutch All 1107 DZJL000350 Bracket, Ground All 1127 DZJF000622 Guide, Paper All 1128 DZJA000662 Bracket, Paper Feed All 1129 DZKK000052 Arm, Latch All 1130 DZJB000175 Base, Reverse All 1131 DZLM000106 Bushing, P6L10 All 1132 DZLG000009 Clutch, Reverse PM All 1133 DZHC000101 Actuator, NP All 1135 DZLF000322 Clutch, C30 Gear All 1136 DZLF000323 Gear, C23 Free All 1137 DZLF000448 Gear, B48 Drive All 1138 DZLF000321 Gear, B30 Drive All
1139 DZLF000320 Gear, B37 Free All 1140 DZJE001104 Guide, Rail All 1141 DZJB000368 Bracket All 1142 DZKG000360 Shaft, Feed All 1143 DZKG000365 Shaft, Reverse All 1144 DZLA000203 Roller, Paper Feed PM All 1145 DZLA000202 Roller, C25 Gear PM All 1146 DZHP008920 Assembly, Reverse Clutch PM All 1147 DZKQ000030 Spring, B All 1148 DZKQ000028 Spring, C All 1149 DZKN000389 Spring, Roller All 1150 DZLM000006 Bushing, P6L5 All 1152 FFPXA74H003C Motor, Lift DC All 1153 DZJM000440 Stopper, Paper Tray All 1155 DZKN000227 Spring 1, Ground All 1161 DZJM000474 Sheet, Protection All
