5.8. Process Unit (3/3)
841
DZHP008303
Asse (For DP-2310/3010)
mbly, Developer Unit
All
DZHP010728
Asse (For DP-2330/3030)
mbly, Developer Unit
All
842 DZJM001256 Seal 2, Supply Mouth All 843 DZJM001258 Seal 3, Supply Mouth All 844 DZJM001259 Seal 4, Supply Mouth All 845 DZNE000110 Sheet, Magnet Roller All 846 DZNK005031 Label, Green All 847 DZJM001267 Sheet, Cover All 723 DZJL000362 Plate, Nut All
19
XTB3+8JFJ
Screw (For DP-2310/3010 only)
Screw
All
XTB3+8J All
F9 XTN3+10G Screw All H6 FFPFJ0033B Snap Ring All J8 XUC7VM E-Ring All
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
801 DZLA000338 Roller, Magnet All 802 DZLM000193 Bearing, Magnet Roller All 804 DZJB000364 Shield, Front Magnet Roller All 805 DZUF000004 Paddle, String All 806 DZLM000194 Bearing, Paddle All 807 DZUF000005 Screw 1, Carriage All 808 DZUF000006 Screw 2, Carriage All 809 DZJF000617 Blade, Doctor All 810 DZNE000092 Sheet, Splash Prevention All 811 DZHE000047 Sponge All 812 DZJE001101 Plate, Sub All 813 DZJF000619 Plate, High Voltage Charge All 814 DZJF000620 Plate, Developer Bias All 815 DZJF000621 Plate, Support Magnetic All 816 DZKN000376 Spring, Front Developer Bias All 817 DZKN000377 Spring, Rear Developer Bias All 818 DZLB000056 Coupling, Magnet All 819 DZLF000654 Gear, Paddle All 820 DZLF000655 Gear, Screw 1 All 821 DZLF000656 Gear, Idle All 822 DZLF000657 Gear, Screw 2 All 823 DZKG000359 Pin, Idle Gear All 824 DZJB000366 Frame, Developer All 825 DZJB000367 Cover, Developer All 826 DZNE000093 Cover, Developer Harness All 827 DZJF000618 Cover, Under Magnet Roller All 828 DZJB000365 Shield, Rear Magnet Roller All 829 DZNE000094 Sheet, Guide All 830 DZJM001226 Seal, Supply Mouth All 831 DZJE001102
Holder, Toner Waste Container
All
833 DZLM000157 Bearing, Front Screw All 834 DZLM000159 Bearing, Rear Screw All
839 DZQJ000053 Poly Slider All 840 DZJN000073 O-Ring All
835 DZLM000155 Bearing, Idle Gear All 837 DZJL000215 Holder, TDC Sensor All 838 DZAN000006 Sensor, TDC All
