Panasonic DP-2330

268
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.41. 1-Bin Finisher Packing and Accesories
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
4101 PF4124P080 Carton Box All 4104 DZSM000689 Installation Instructions All 4105 PF4124K110 Assembly, Cushion All 1912
LVPS, Optional (See Sect 21 & 22 PC Boards/Harnesses)
1947 DZFP001448 Harness, FNS All 1948 DZFP001407 Harness, LVS2 All 1983 PF4117P003 PC Board, IPC All 2520 PF2252P619 Snap Ring All 2522 PF4124K127 Assembly, Finisher Tray All 2623 PF4124P001 Bracket, Base All 2626 PF4124P002 Bracket, Front Slide Guide All 2627 PF4124P003 Bracket, Rear Slide Guide All 2631 PF4124P023 Screw All
6P
XTW3+6LFJ Screw
Screw (For DP-2310/3010 only)
All
XTW3+6LFC All
