Panasonic DP-2330

212
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.20. Paper Tray
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
2001 DZJF000432 Base, Paper Tray All 2002
DZMC000806
Cover, Tray (2nd/3rd/4th Paper Tray)
All
DZMC000808
2003 DZJF000412 Paper Guide, Front All 2004 DZJF000413 Paper Guide, Rear All 2005 DZJF000414 Paper Guide, Left All 2006 DZLA000198 Roller, Paper Tray All 2007
DZMC000810
Cover, Sub Tray (For 1st Paper Tray) (For DP-2310/3010) Cover, Sub Tray (For 2nd/3rd/4th Paper Tray) (For DP-2310/3010) Cover, Sub Tray (For 1st Paper Tray) (For DP-2330/3030) Cover, Sub Tray (For 2nd/3rd/4th Paper Tray) (For DP-2330/3030)
All
DZMC000812 DZMC000829
DZMC000828
2008 DZKM000021 Plate, Bottom All 2009 DZJL000116 Plate, Lift All 2010 DZKG000117 Shaft, Arm All 2014 DZLF000019 Gear, Guide All 2015 DZPG000011 Pin, Spring All 2016 DZKM000027 Pad, Brake All 2017 DZNK004935 Label All 2018 DZNK004918 Log, Service Mode A 2020 DZNE000125 Film, Guide All
ll
2117
DZNK004940
Label, Tray
PU
DZNK004942
Except PU, PK, PH, PT
DZNK005380 PK, PH, PT
23
XYN3+F8FJ Screw All XYN3+F8 All
Screw (For DP-2310/3010 only)
Cover, Tray (1st Paper Tray)
S9 DZJM000171 Snap Ring All
4N
XSN3+W8FJ Screw
Screw (For DP-2310/3010 only)
All
XSN3+W8FC All
