Panasonic DP-2330

252
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.33. ADF (3/3)
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
1881 DZKQ000051 Spring, B1 Sensor All 1882 DZJM001284 Film, Guide A Except PU 1886 DZJL000380 Plate, Heat Sink 1 All 1887 DZJM001283 Sheet, Guide B All 1888 DZJM001288 Sheet, AL All 1889 PJMDC0029Z Plate, Heat Sink 2 All 1890 DZJK000046 Clamp All 1674 DZJK000045 Clamp All 1951
DZFP001705
Harness, AMT (For DP-2330/3030)
All
DZFP001536 All
1955
DZFP001674
Harness, B1S (For DP-2330/3030) Harness, AMT (For DP-2310/3010) Harness, B1S (For DP-2310/3010)
All
DZFP001439 All
19
XTB3+8JFJ Screw All XTB3+8J
All
24
XYN4+F8FJ
Screw
All
XYN4+F8 All
62
XTB3+6JFJ
Screw Screw (For DP-2310/3010 only) Screw (For DP-2310/3010 only) Screw (For DP-2310/3010 only)
All
XTB3+6J All
S9 DZJM000171 Snap Ring All
3301 DZMA002363 Cover, ADF Exit Except PU 3302 DZJA000703 Bracket, Rear Guide Except PU 3303 DZJA000702 Bracket, Front Guide Except PU 3304 DZJA000704 Bracket, Motor Except PU 3305 DZLF000336 Gear F, E26S35 Except PU 3306 DZJM000495 Film S, Exit Except PU 1045
DZAL000211
Photo Sensor (For DP-2330/3030) Photo Sensor (For DP-2310/3010)
All
DZAL000072 All
1621 DZJL000115 Bushing All 1626 DZKP000208 Plate Spring, Pinch Roller All 1627 DZLA000080 Roller, Pinch All 1663 DZJA000696 Bracket, Sensor All 1716 DZLF000036 Gear, E25 All 1801 DZGG000046 Motor, ADF All 1806 DZLF000283 Gear, E29 All 1807 DZLF000333 Gear, E21E27 All 1812 DZLB000013 Pulley All 1814 DZLK000013 Belt, Timing All 1815 DZJA000698 Bracket, Pulley All 1830 DZJA000675 Bracket, Actuator All 1831 DZMA002329 Cover, ADF All 1832 DZKN000126 Spring, Gear All 1833 DZMG000018 Latch All 1834 DZJA000681 Bracket, Rear ADF Cover All 1835 DZJA000680 Bracket, Front ADF Cover All 1836 DZHC000102 Actuator 1 All 1837 DZKG000108 Shaft, Pinch Roller All 1838 DZLA000211 Roller, Pinch All 1839 DZKP000204 Plate Spring 2, Discharge All 1840 DZJA000677 Plate 1, Adjustment All 1841 DZHC000103 Actuator 2 All 1842 DZJM000407 Cover, Sub ADF All 1843 DZKP000200 Plate Spring, Pinch Roller All 1850 DZKP000206 Plate Spring, Ground All
1855 DZGT000007 Brush, Antistatic All 1861 DZJM000427 Guide, Upper Feed All 1862 DZJA000688 Guide, Skew All 1863 DZKG000112 Shaft, Drive Pinch All 1864 DZKP000207 Plate Spring, Drive All 1866 DZJF000409 Guide, Sub Top All 1880 DZJM000476 Sponge All
