Panasonic DP-2330

170
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
5.11. Paper Feed Module
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
1101 DZJB000168 Frame, Paper Tray All 1102 DZLF000446 Gear, D17 Drive All 1103 DZLM000196 Collar, Feed All 1104 DZJA001297 Guide, Process Unit All 1105 DZGA000038 Clutch All 1106 DZJL000373 Plate Nut All 1107 DZJL000350 Bracket, Ground All 1110 DZJB000414 Base Frame All 1118 DZKN000179 Spring A, Contact All 1119 DZKN000180 Spring B, Contact All 1120 DZHC000100 Actuator, Registration All 1121 DZLA000336 Roller, Registration PM All 1122 DZKQ000104
Spring, Registration Actuator
All
1127 DZJF000622 Guide, Paper All 1128 DZJA000662 Bracket, Paper Feed All 1129 DZKK000052 Arm, Latch All 1130 DZJB000175 Base, Reverse All 1131 DZLM000106 Bushing, P6L10 All 1132 DZLG000009 Clutch, Reverse PM All 1133 DZHC000101 Actuator, NP All 1135 DZLF000322 Clutch, C30 Gear All 1136 DZLF000323 Gear, C23 Free All 1137 DZLF000448 Gear, B48 Drive All 1138 DZLF000321 Gear, B30 Drive All 1139 DZLF000320 Gear, B37 Free All 1140 DZJE001104 Guide, Rail All 1141 DZJB000368 Bracket All 1142 DZKG000360 Shaft, Feed All 1143 DZKG000365 Shaft, Reverse All 1144 DZLA000203 Roller, Paper Feed PM All 1145
DZLA000202
Roller, C25 Gear
PM All
1146 DZHP008920 Assembly, Reverse Clutch PM All 1147 DZKQ000030 Spring, B All
1150 DZLM000006 Bushing, P6L5 All 1152 FFPXA74H003C Assembly, Lift DC Motor All 1153 DZJM000440 Stopper, Paper Tray All 1155 DZKN000227 Spring 1, Ground All 1161 DZJM000474 Sheet, Protection All 1162 FFPKE10251 Box, Lift All 1163 FFPKE10261 Cover, Box All 1164 FFPMF10271 Gear 1 All 1165 FFPMF10281 Gear 2 All 1166 FFPMF1029 Gear 3 All 1167 FFPMF1030 Gear 4 All 1168
FFPXA73H004
Motor, Lift
All
1169
FFPMF1031
Gear, Worm
All
1170 FFPLP0976 Spring, Reset All 1171 FFPHQ0063 Coupling All
1172 FFPFJ00441 Ring, Stopper All 1173 DZLM000103 Collar All 1177 DZNE000107 Sheet, 1st All 1179 DZNE000099 Sheet, Feed All 1180 DZNE000100 Sheet, Feed 2 All 1181 DZNE000114 Sheet, Front Chassis All
417 DZJB000362 Chassis, Front All 418 DZJB000363 Chassis, Rear All 972 DZLM000052 Bushing, P6L5 Conductive All
(For DP-2310/3010)
DZLA000407
Roller, C25 Gear
PM All
(For DP-2330/3030)
(For DP-2310/3010) (For DP-2310/3010)
FFPMF1031B
Gear, Worm
All
(For DP-2330/3030)
FFPXA73H004B
Motor, Lift
All
(For DP-2330/3030)
1148 DZKQ000028 Spring, C All 1149
DZKN000389
Spring, Roller
All
(For DP-2310/3010)
DZKN000423
Spring, Roller
All
(For DP-2330/3030)
