Panasonic DP-2330

138
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
131 DZDN000105 Ferrite Core Except PU 132 DZNM000006 Logo, Panasonic All
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
1999 DZFP001543 Harness, PNL1-INV All
19100 DZFP001544 Harness, PNL1-FG All
F10
XTB3+8GFJ
Screw Screw
All
XTB3+8G All
H4
XTB26+8JFJ
Screw Screw
All
XTB26+8J
All
P5 XTN3+8G Screw All S6 DZPA000086 Screw All
(For DP-2310/3010 only) (For DP-2310/3010 only)
1908
PC Board, PNL1 (See Sect 21 & 22 PC Boards/Harnesses RTL/PbF)
130
DZHP008628
Control Panel Unit (For DP-2310) Control Panel Unit (For DP-3010) Control Panel Unit (For DP-2330) Control Panel Unit (For DP-3030)
PU
DZHP008903 PF DZHP009647 PH DZHP009282 PK DZHP009394 PL DZHP008904 PM DZHP009278 PP DZHP009651 PR DZHP009450 PS DZHP009625 PT DZHP008905 PX DZHP008629 Other DZHP008391 PU DZHP008901 PF DZHP009607 PH DZHP009281 PK DZHP009393 PL DZHP008900 PM DZHP009277 PP DZHP009650 PR DZHP009448 PS DZHP009618 PT DZHP008902 PX DZHP008487 Other DZHP010682
PU
DZHP010680
127 DZTE000044 Touch Panel All 128 DZDA000041 LCD Module All 129 DZEA000070 PC Board, Inverter All
1997 DZFP001541 Harness, PNL1-2 All 1998 DZFP001542 Harness, PNL1-3 All
