164
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
Ref.
No.
Part Number Part Name
PM/
RTL
Destination
459 FBA08A24HC0 Fan All
1045
DZAL000211
Photo Sensor
(For DP-2330/3030)
Photo Sensor
(For DP-2310/3010)
All
DZAL000072 All
1926
DZFP001738
Harness, MT
(For DP-2330/3030)
All
DZFP001426 All
1928
DZFP001739
Harness, BMT
(For DP-2330/3030)
All
DZFP001429 All
1944
DZFP001668
Harness, FM
(For DP-2330/3030)
All
DZFP001430 All
19120
DZFP001691
Harness, BHP
(For DP-2330/3030)
Harness, MT
(For DP-2310/3010)
Harness, BMT
(For DP-2310/3010)
Harness, FM
(For DP-2310/3010)
Harness, BHP
(For DP-2310/3010)
All
DZFP001508 All
19
XTB3+8JFJ
Screw
(For DP-2310/3010 only)
All
XTB3+8J All
24
XYN4+F8FJ
Screw
(For DP-2310/3010 only)
All
XYN4+F8 All
Screw
Screw
Note
This assembly does not include Ref. No. 975 and 1928.
6P
XTW3+6LFJ
Screw
(For DP-2310/3010 only)
All
XTW3+6LFC All
E5
XTB3+32JFJ
Screw
(For DP-2310/3010 only)
Screw
Screw All
XTB3+32J All
974 DZJF000624 Duct 1, Fan All
975 DZNE000102 Sheet, Gear All
976 DZLM000202 Bearing All
977 DZJM001254 Sheet, Motor All
979 DZHA000214 Sheet, Bracket All
Ref.
No.
Part Number Part Name
PM/
RTL
Destination
G6 FFPFJ0039B Snap Ring All
H7 FFPFJ0041B Snap Ring All
S9 DZJM000171 Snap Ring All
T4
XYN3+F5FJ
Screw
(For DP-2310/3010 only)
Screw
All
XYN3+F5FY All
