Panasonic DP-2330

178
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
1935
DZFP001742
Harness, HPE (For DP-2330/3030) Harness, HPE (For DP-2310/3010)
All
DZFP001442 All
1981 DZEC102304 PC Board, SNS All 1986 DZEC102793 PC Board, CDS (PbF) All 1991
DZFP001665
Harness, MFS (For DP-2330/3030)
All
DZFP001425 All
1992
DZFP001734
Harness, CDS (For DP-2330/3030) Harness, MFS (For DP-2310/3010) Harness, CDS (For DP-2310/3010)
All
DZFP001417 All
19
XTB3+8JFJ Screw All XTB3+8J All
23
XYN3+F8FJ Screw All XYN3+F8 All
36
XYN3+F6FJ
Screw
All
XYN3+F6
All
64
XWG3FJ Washer All XWG3 All
7B
XTB26+6JFJ Screw All XTB26+6J All
B1 DZPB000007 Screw, Silver All C8
XTW3+8SFJ Screw
Screw (For DP-2310/3010 only) Screw (For DP-2310/3010 only)
Screw (For DP-2310/3010 only) Washer (For DP-2310/3010 only) Screw (For DP-2310/3010 only) Screw (For DP-2310/3010 only)
All
XTW3+8SFC All
G6 FFPFJ0039B Snap Ring All J7 XUC4VM E-Ring All S9 DZJM000171 Snap Ring All
