Panasonic DP-2330

192
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
1954
DZFP001725
Harness, SNS (For DP-2310/3010) Harness, SNS (For DP-2330/3030)
PK
DZFP001711 Except PK DZFP000912 PH, PK, PT DZFP000892
Except PH, PK, PT
1955
DZFP001674
Harness, B1S (For DP-2330/3030) Harness, B1S (For DP-2310/3010)
All
DZFP001439 All
1981 DZEC102304 PC Board, SNS All
19
XTB3+8JFJ Screw
Screw (For DP-2310/3010 only)
All
XTB3+8J All
5Y
XUC4FJ E-Ring All XUC4
All
B1 DZPB000007 Screw, Silver All B4
XTB3+8JFI
Screw
All
XTB3+8JFK All
E8
XTW3+10SFJ Screw All XTW3+10S All
F7 XSN4+W10FN Screw, Silver All M2 DZPA000064 Thumb Screw All P2
XTB3+12JFJ Screw
E-Ring (For DP-2310/3010 only) Screw (For DP-2310/3010 only) Screw (For DP-2310/3010 only) Screw (For DP-2310/3010 only)
All
XTB3+12J All
S9 DZJM000171 Snap Ring All
* : This assembly does not include the parts with Ref. No. 1636, 1638,
1655, 1656, 1657 and M2.
1701 DZLM000007 Bushing, P6L7.4 All 1907 DZEC101648 PC Board, ADF (i-ADF)(PbF) RTL All
