Panasonic DP-2330

196
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
1785 DZJM000491 Film, Reversing Guide 1 All 1786 DZKN000203
Spring, Hinge (Silver, i-ADF)
All
1787 DZGA000008 Clutch All 1788 DZGA000007 Clutch All 1789 DZJM000888 Film All 1790 DZHP003955 Assembly, Torque Limiter All
744 DZPG000001 Pin All
1008 DZLM000109 Bushing, P3.5L5 All 1045
DZAL000211
Photo Sensor (For DP-2330/3030)
All
DZAL000072 All
1417 DZPK000017 Washer, Polyethylene All 1621 DZJL000115 Bushing All 1622 DZJA000724 Hinge, Arm All 1623 DZJA000727 Plate, Reinforcement All 1624 DZKG000124 Shaft, P6 All 1627 DZLA000080 Roller, Pinch All 1655 DZJA000730 Bracket, ADF Mounting All 1656 DZMC000713 Cover, Hinge All 1657 DZJA000726 Stopper, Hinge All 1658 DZJM000449 Film, Hinge All 1664 DZJA000725 Base, Left Hinge (A) All 1833 DZMG000018 Latch All 1855 DZGT000007 Brush, Antistatic All 1951
DZFP001705
Harness, AMT (For DP-2330/3030)
All
DZFP001536 All
1953
DZFP001710
Harness, CLT (For DP-2330/3030)
All
DZFP000891 All
1956
DZFP001712
Harness, APNT (For DP-2330/3030)
All
DZFP000906 All
Photo Sensor (For DP-2310/3010) Harness, AMT (For DP-2310/3010) Harness, CLT (For DP-2310/3010) Harness, APNT (For DP-2310/3010)
1957
DZFP001713
Harness, EXT (i-ADF) (For DP-2330/3030) Harness, EXT (i-ADF) (For DP-2310/3010)
All
DZFP000895 All
19
XTB3+8JFJ
Screw (For DP-2310/3010 only)
All
XTB3+8J
All
24
XYN4+F8FJ
Screw (For DP-2310/3010 only)
All
XYN4+F8 All
5M
XYN3+F4FJ
Screw (For DP-2310/3010 only)
All
XYN3+F4 All
5Y
XUC4FJ
E-Ring (For DP-2310/3010 only)
All
XUC4 All
5Z
XUC6FJ
E-Ring (For DP-2310/3010 only)
All
XUC6 All
H7 FFPFJ0041B Snap Ring All M2 DZPA000064 Thumb Screw All P2
XTB3+12JFJ
Screw (For DP-2310/3010 only) Screw Screw Screw E-Ring E-Ring Screw All
XTB3+12J All
S9 DZJM000171 Snap Ring All
