Panasonic DP-2330

206
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
1936
DZFP001685
Harness, CSS (For DP-2330/3030) Harness, CSS (For DP-2310/3010)
PU
PJJRC2584Z Other DZFP001464 All
1937
DZFP001895
Harness, QPM (For DP-2330/3030)
All
DZFP001366 All
1938
DZFP001678
Harness, EXFC (For DP-2330/3030)
All
DZFP001453 All
1939
DZFP001675
Harness, DUXC (For DP-2330/3030)
All
DZFP001440 All
1940
DZFP001743
Harness, SW3C (For DP-2330/3030)
All
DZFP001449 All
1941
DZFP001741
Harness, CCD (For DP-2330/3030)
All
DZFP001436 All
1942
DZFP001499
Harness, HD
PU
DZFP001526 Other
1943
DZFP001740
Harness, SDR (For DP-2330/3030)
All
DZFP001434 All
1944
DZFP001668
Harness, FM (For DP-2330/3030) Harness, QPM (For DP-2310/3010) Harness, EXFC (For DP-2310/3010) Harness, DUXC (For DP-2310/3010) Harness, SW3C (For DP-2310/3010)
Harness, CCD (For DP-2310/3010)
Harness, SDR (For DP-2310/3010) Harness, FM (For DP-2310/3010)
All
DZFP001430 All
1945
DZFP001680
Harness, CST2 (For DP-2310/3010) (For 4nd Paper Feed Module) Harness, CST2 (For DP-2310/3010) (For 2th Paper Feed Module) Harness, CST2 (For DP-2330/3030) (For 4nd Paper Feed Module) Harness, CST2 (For DP-2330/3030) (For 2th Paper Feed Modul)
All PU
DZFP001697 Other DZFP001455
All PU
DZFP001524 Other
1946
DZFP001735
Harness, MBS (For DP-2330/3030)
All
DZFP001418 All
1947
DZFP001727
Harness, FNS (For DP-2330/3030)
All
DZFP001448 All
1948
DZFP001730
Harness, LVS2 (For DP-2330/3030)
All
DZFP001407 All
1949
DZFP001687
Harness, DC12 (For DP-2330/3030)
All
DZFP001468 All
1950
DZFP001709
Harness, ADF (For DP-2330/3030)
All
DZFP000888 All
1951
DZFP001705
Harness, AMT (For DP-2330/3030) Harness, MBS (For DP-2310/3010) Harness, FNS (For DP-2310/3010) Harness, LVS2 (For DP-2310/3010) Harness, DC12 (For DP-2310/3010) Harness, ADF (For DP-2310/3010) Harness, AMT (For DP-2310/3010)
All
DZFP001536 All
