Panasonic DP-2330

210
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
2851 PF4102K212 Harness, Top Cover Sensor All 2931 PF4102K221 Motor, Set All 2933 PF4102K213 Harness, Paper Exit Sensor All 2944 PF4102K211 Harness, SW All 3014 PF4115K220 Motor, Drive All 3026 PF4124K600 Harness, Interface All 3028 PF4124K502 PC Board, CONT All 3029 PF4124K602 Harness, Drive Motor All
1970
DZFP001386
Harness, SDR-INV (For DP-2330/3030) Harness, SDR-INV (For DP-2310/3010)
All
DZFP000903 All
1971
Hardware Key (Available as a Sales Item)
All
1972 DZEC102137 PC Board, FRM 8 (PbF) All 1977 DZFP001501 Harness, HT2 All 1978 DZEC101608 PC Board, EXFD (PbF) RTL All 1979
DZFP001718
Harness, EXFD 2 (For DP-2330/3030) Harness, EXFD 2 (For DP-2310/3010)
All
DZFP001001 All
1980
DZFP001719
Harness, EXFD SEN (For DP-2330/3030) Harness, EXFD SEN (For DP-2310/3010)
All
DZFP001002 All
1983 PF4117P003 PC Board, IPC All 1985
DZFP001749
Harness, ACD (For DP-2330/3030) Harness, ACD (For DP-2310/3010)
All
DZFP001522 All
1987
DZFP001747
Harness, EXM (For DP-2330/3030) Harness, EXM (For DP-2310/3010)
All
DZFP001473 All
1988
DZFP001702
Harness, CL2 (For DP-2330/3030) Harness, CL2 (For DP-2310/3010)
All
DZFP001530 All
1989
DZFP001701
Harness, JDR 3 (For DP-2330/3030) Harness, JDR 3 (For DP-2310/3010)
All
DZFP001529 All
1995 DZFP000928 Harness, KEY All 1997 DZFP001541 Harness, PNL1-2 All 1998 DZFP001542 Harness, PNL1-3 All 1999 DZFP001543 Harness, PNL1-INV All
19103
DZFP001688
Harness, RLB (For DP-2330/3030) Harness, RLB (For DP-2310/3010)
All
DZFP001469 All
19118
DZFP001708
Harness, HT2 (For DP-2330/3030) Harness, HT2 (For DP-2310/3010)
All
DZFP000896 All
19119
DZFP001707
Harness, HT4 (For DP-2330/3030) Harness, HT4 (For DP-2310/3010)
All
DZFP001538 All
127 DZTE000044 Touch Panel All 128 DZDA000041 LCD Module All 950 DZGA000009 Clutch, OPC All
1321 DZGB000026 Solenoid All 1635 DZHP003774 Solenoid, Stamp All 2629 PF4124K603 Assembly, Harness All 2710 PF4102K222 Solenoid, Paper Detection All 2728 PF4102P513 Solenoid, Paddle All
