Panasonic DP-2330

230
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
Ref.
No.
Part Number Part Name
PM/ RTL
Destination
1989
DZFP001701
Harness, JDR 3 (For DP-2330/3030)
All
DZFP001529 All
19117
DZFP001715
Harness, HT5 (For DP-2330/3030) Harness, JDR 3 (For DP-2310/3010) Harness, HT5 (For DP-2310/3010)
All
DZFP000981 All
2006 DZLA000198 Roller, Paper Tray All 2301 DZJF000418 Paper Guide 2 All 2302 DZJB000182 Base Frame All 2303 DZJE000270 Cover, Sensor All 2304 DZHC000107 Actuator 2 All 2305 DZKQ000035 Spring, Actuator All 2306 DZLA000342 Roller, Intermediate All 2307 DZMB000014 Cover, Jam Access All 2308 DZMG000015 Magnet All 2309 DZKP000084 Plate Spring, Pinch Roller All 2310 DZJA001308 Bracket, Intermediate All 2316 DZMH000010 Bracket, Front All 2317 DZMH000011 Bracket, Rear All 2323 DZMC000705 Cover, Rear 2 All 2324 DZJA000723 Bracket All 2327 DZNE000101 Sheet, Feed 3 All
19
XTB3+8JFJ Screw All XTB3+8J All
1Y
XTB3+10JFJ Screw All XTB3+10J All
5Y
XUC4FJ
E-Ring
All
XUC4 All
L9
XTB3+4FFJ
Screw Screw (For DP-2310/3010 only) Screw (For DP-2310/3010 only) E-Ring (For DP-2310/3010 only) Screw (For DP-2310/3010 only)
All
XTB3+4F
All
S6 DZPA000086 Screw All
S9 DZJM000171 Snap Ring All
