Panasonic DP-2330

276
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
DZEZ000093
PC Board, SC (For DP-3010)
1901
PX
DZEZ000094 PU
DZEZ000095
Except PU, PM, PF, PG,
PT, PK, PX, PP, PL, PS,
PR, PH
DZEZ000097 PM
DZEZ000098 PF
DZEZ000099 PG
DZEZ000100 PT
DZEZ000101 PK
DZEZ000102 PP
DZEZ000103 PC Board, SC (For DP-2310) PP
DZEZ000104 PC Board, SC (For DP-3010) PL
DZEZ000105 PC Board, SC (For DP-2310) PL
DZEZ000106 PC Board, SC (For DP-3010) PS
DZEZ000107 PC Board, SC (For DP-2310) PS
DZEZ000110 PC Board, SC (For DP-3010) PR
DZEZ000111 PC Board, SC (For DP-2310) PR
DZEZ000112 PC Board, SC (For DP-3010) PH
DZEZ000113 PC Board, SC (For DP-2310) PH
DZEZ000118 PC Board, SC (For DP-2330) PU
DZEZ000119 PC Board, SC (For DP-3030) PU
DZFB000001
PTT Plug 3706
AR
DZFB000009 AL
DZFB000010 AL
DZFB000035 AR
DZFC000231 Connector 2 1777 All
DZFC000232 Connector 3 1778 All
DZFM000031
Cord, AC Power 2112
PA
DZFM000072 PU, PT
DZFM000075 PA
DZFN000009
Cord, Telephone Line 3703
AU
DZFN000015 EE
DZFN000017 AL
DZFN000026 EE
DZFN000030 AH
DZFN000050
AJ, AU, YC, YG, YK, YR,
YV, YW, YX
DZFN000069 AG
DZFN000078 EE
DZFN000095 AB, AK, AW
DZFN000096 AM
DZFN000104 AM, AR, AV
DZFN000105
PTT Plug 3706
AV
DZFN000108 AM
DZFN000114
Cord, Telephone Line 3703
AB
DZFN000120 AB, AK, AW
DZFP000747 Resistor, 200M Ohms 1230 All
DZFP000863
Harness, Paper Tray Sensor
(For DP-2310/3010)
1966 All
DZFP000870 Harness, FPC (For DP-2310/3010) 1962 All
DZFP000888 Harness, ADF (For DP-2310/3010) 1950 All
DZFP000891 Harness, CLT (For DP-2310/3010) 1953 All
DZFP000892 Harness, SNS (For DP-2310/3010) 1954 Except PH, PK, PT
Alphanumerical Parts List
Part Number Part Name Ref. No. PM Destination
