284
DP-2330/3030
DEC 2004
Ver.2.0
DP-2310/3010
DZJA000719 Bracket, Motor 1312 All
DZJA000721 Bracket S, B2 Sensor 3204 Except PU
DZJA000722 Guide, Feed 2 Roller 3206 Except PU
DZJA000723 Bracket 2324 All
DZJA000724 Hinge, Arm 1622 All
DZJA000725 Base, Left Hinge (A) 1664 All
DZJA000726 Stopper, Hinge 1657 All
DZJA000727 Plate, Reinforcement 1623 All
DZJA000728 Base, Right Hinge (B) 1625 All
DZJA000730 Bracket, ADF Mounting 1655 All
DZJA000732 Bracket, Hinge 505 All
DZJA000735 Bracket, Outer Tray 554 All
DZJA000736 Bracket, Outer Roller B 552 All
DZJA000741 Plate Spring, Mirror 1 252 All
DZJA000784 Bracket, Fan 463 All
DZJA000786 Bracket, KC 566 All
DZJA000813 Bracket, Idle 1327 All
DZJA000824 Bracket, Arm 568 All
DZJA001292 Guide, Tray (For DP-2310/3010) 1202 All
DZJA001293 Bracket, Front Right Cover 1246 All
DZJA001294 Bracket, Rear Left Cover 1247 All
DZJA001295 Bracket, Front Guide 1240 All
DZJA001296 Bracket, Rear Guide 1241 All
DZJA001297 Guide, Process Unit 1104 All
DZJA001298 Plate, Ground 428 All
DZJA001299 Bracket 2, Gear 1408 All
DZJA001300 Bracket 1, Drive 2403 All
DZJA001301 Bracket 2, Drive 2404 All
DZJA001302 Bracket, 1st Tray Drive 939 All
DZJA001303 Bracket, Drive 2313 All
DZJA001304 Bracket, Motor 908 All
DZJA001305 Bracket, Gear 909 All
DZJA001306 Bracket, 1st Tray Drive Sub 911 All
DZJA001307 Bracket, Duplex 1413 All
DZJA001308 Bracket, Intermediate 2310 All
DZJA001309 Bracket, FB 515 All
DZJA001310 Bracket, Switch 312 All
DZJA001311 Bracket, LED 319 All
DZJA001313 Bracket, FAX PCB 310 All
DZJA001314 Bracket, LVPS Cover 408 All
DZJA001315 Rail, Guide 318 All
DZJA001316 Bracket, Rear Cover 305 All
DZJA001318 Bracket, ILS 317 All
DZJA001319 Bracket, Left LSU 422 All
DZJA001320 Cover, LVPS 301 All
DZJA001322 Bracket, Right LSU 421 All
DZJA001323 Assembly, Roof Frame 415 All
DZJA001324 Assembly, Rear Frame 401 All
DZJA001327 Bracket, LSU Fan 316 All
DZJA001328 Plate, Protection 2401 All
DZJA001329 Bracket, Sensor 966 All
DZJA001333 Bracket, Choke Coil 1 324 Except PU
DZJA001350 Guide, Cable 332 All
Alphanumerical Parts List
Part Number Part Name Ref. No. PM Destination
