Panasonic DP-3000 User Manual

230
DA3 MA724 SCHOTTKY BARRIER DIODE
IC1 DZAC000208 16BIT MICROCONTROLER
IC10 DZZZ999999 Not Mounted
IC11 DZAA001060 FLASH MEMORY
or DZAA001091 FLASH MEMORY
IC12 DZAA001154 FLASH MEMORY
IC13 DZZZ999999 Not Mounted
IC14 DZAC000020 GATE ARRAY
IC15 DZAA000977 VHCMOS
or DZAA000727 VHCMOS
IC16 DZAA000977 VHCMOS
or DZAA000727 VHCMOS
IC17 DZAA000977 VHCMOS
or DZAA000727 VHCMOS
IC18 DZAA000977 VHCMOS
or DZAA000727 VHCMOS
IC19 DZZZ999999 Not Mounted
IC2 DZAA000978 OCTAL BUS BUFFER
IC20 DZZZ999999 Not Mounted
IC21 DZZZ999999 Not Mounted
IC22 DZZZ999999 Not Mounted
IC23 DZZZ999999 Not Mounted
IC24 DZZZ999999 Not Mounted
IC25 DZZZ999999 Not Mounted
IC28 DZAC000234 GATE ARRAY
IC29 DZAA001102 SD-RAM
IC3 DZAA000095 TRIPLE INVERTER
IC30 DZAA001101 SD-RAM
or DZAA001339 SD-RAM
or DZAA001337 SD-RAM
or DZAA001338 SD-RAM
IC31 DZAA001101 SD-RAM
or DZAA001339 SD-RAM
or DZAA001338 SD-RAM
or DZAA001337 SD-RAM
IC32 DZAA000095 TRIPLE INVERTER
IC33 DZAA001056 CODEC
IC34 DZAC000233 GATE ARRAY
IC35 DZAA001101 SD-RAM
or DZAA001339 SD-RAM
or DZAA001338 SD-RAM
or DZAA001337 SD-RAM
IC36 DZZZ999999 Not Mounted
IC37 DZAA000978 OCTAL BUS BUFFER
IC38 DZAA000650 TRIPLE INVERTER
IC39 DZAA000978 OCTAL BUS BUFFER
IC4 DZAA000114 RESETTING IC
IC40 DZAA001098 MUTIPLEXER
IC41 DZAA001099 MUTIPLEXER
IC42 DZAA001083 MUTIPLEXER
IC46 DZAA001058 PWM
IC47 DZAA001075 NOR GATE
IC48 DZZZ999999 Not Mounted
IC49 DZAA001072 LVDS
IC5 DZAC000166 GATE ARRAY
IC50 DZZZ999999 Not Mounted
IC51 MN86076 GATE ARRAY
IC52 DZAA000095 TRIPLE INVERTER
IC53 DZZZ999999 Not Mounted
IC54 AN2190FHQ DIGITAL COPY SIGNAL PROCESSER
IC55 AN8133FHQ A/D CONVERTER
IC56 DZAA000295 AND GATE
IC57 DZZZ999999 Not Mounted
IC58 DZAA000295 AND GATE
IC59 DZAA001201 LINEAR REGULATOR
IC6 DZAA000769 LMOS
Safety
Mark
Ref. No. Part Number Part Name Description

Panasonic DP-3000 Specifications

General

Brand	Panasonic
Model	DP-3000
Category	Copier
Language	English
