Panasonic DP-3000 User Manual

299
3.27. SDRM PC Board (128MB)
3.28. SNS PC Board
or DZAA001337 SD-RAM
or DZAA001338 SD-RAM
or DZAA001339 SD-RAM
IC4 DZZZ999999 Not Mounted
IC5 DZZZ999999 Not Mounted
IC6 DZZZ999999 Not Mounted
IC7 DZZZ999999 Not Mounted
IC8 DZZZ999999 Not Mounted
PCB DZEP000475 PC BOARD, SDRM
R1 ERJ3GEY0R00B RESISTOR, CHIP 0µ, 1/16W
R2 DZZZ999999 Not Mounted
R3 DZZZ999999 Not Mounted
Safety
Mark
Ref. No. Part Number Part Name Description
C1 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C10 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C11 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C12 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C13 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C14 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C15 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C16 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C17 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C2 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C3 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C4 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C5 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C6 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C7 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C8 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C9 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
IC1 DZAA001122 SD-RAM
IC2 DZAA001122 SD-RAM
IC3 DZAA001122 SD-RAM
IC4 DZAA001122 SD-RAM
IC5 DZAA001122 SD-RAM
IC6 DZAA001122 SD-RAM
IC7 DZAA001122 SD-RAM
IC8 DZAA001122 SD-RAM
PCB DZEP000475 PC BOARD, SDRM
R1 DZZZ999999 Not Mounted
R2 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
R3 DZZZ999999 Not Mounted
Safety
Mark
Ref. No. Part Number Part Name Description
CNP41 DZFC000076 CONNECTOR
PC1 DZAL000052 PHOTO-INTERRUPTER
PC2 DZAL000052 PHOTO-INTERRUPTER
PCB DZEP000474 PC BOARD, SNS
R1 ERDS2TJ181 RESISTOR, CARBON FILM 180Ω, 1/4W
Safety
Mark
Ref. No. Part Number Part Name Description
