3.5. LPC PC Board (DP-3000)
Safety
Mark
Ref. No. Part Number Part Name Description
1 DZAA001052 FLASH MEMORY
C101 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C102 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C103 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C105 DZBA000213 CAPACITOR, CERAMIC 15pF, 50VDC
C106 DZBA000221 CAPACITOR, CERAMIC 18pF, 50VDC
C108 EEVHA1C100R CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C109 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C110 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C111 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C112 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C113 DZBA000047 CAPACITOR, CERAMIC 1µF, 16VDC
C114 DZBA000047 CAPACITOR, CERAMIC 1µF, 16VDC
C115 DZBA000209 CAPACITOR, CERAMIC 22pF, 50VDC
C116 DZBA000209 CAPACITOR, CERAMIC 22pF, 50VDC
C117 DZZZ999999 Not Mounted
C201 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C202 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C203 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C204 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C205 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C206 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C207 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C305 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C307 DZBA000047 CAPACITOR, CERAMIC 1µF, 16VDC
C308 DZBA000193 CAPACITOR, CERAMIC 0.022µF, 50VDC
C309 DZBA000193 CAPACITOR, CERAMIC 0.022µF, 50VDC
C310 DZBA000193 CAPACITOR, CERAMIC 0.022µF, 50VDC
C311 DZBA000193 CAPACITOR, CERAMIC 0.022µF, 50VDC
C312 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C314 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C315 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C316 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C317 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C318 EEVHA1H100P CAPACITOR, ELECTROLYTIC 10µF, 50VDC
C319 EEVHA1C100R CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C320 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C402 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C409 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C410 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C411 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C412 EEVHA1H100P CAPACITOR, ELECTROLYTIC 10µF, 50VDC
C413 EEVHB1V220P CAPACITOR, ELECTROLYTIC 22µF, 35VDC
C415 EEVHB1C220R CAPACITOR, ELECTROLYTIC 22µF, 16VDC
C417 DZBA000230 CAPACITOR, CERAMIC 1000pF, 25VDC
C418 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C419 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C501 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C505 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C506 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C507 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C600 DZBA000230 CAPACITOR, CERAMIC 1000pF, 25VDC
C601 DZBA000199 CAPACITOR, CERAMIC 100pF, 50VDC
C602 EEVHA1H100P CAPACITOR, ELECTROLYTIC 10µF, 50VDC
C603 DZBA000230 CAPACITOR, CERAMIC 1000pF, 25VDC
C604 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C605 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C606 DZZZ999999 Not Mounted
C701 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C702 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C703 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C704 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C705 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
