3.14. CST3 PC Board (DP-3000)
R66 ERJ6GEYJ471B RESISTOR, CHIP 470Ω, 1/10W
R67 ERJ3GEYJ330B RESISTOR, CHIP 33Ω, 1/16W
R68 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W
R69 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W
R7 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W
R70 ERJ3GEYJ332B RESISTOR, CHIP 3.3KΩ, 1/16W
R71 ERJ3GEYJ332B RESISTOR, CHIP 3.3KΩ, 1/16W
R72 ERX2SJR22 RESISTOR, METAL FILM 0.22Ω, 1W
R73 ERX2SJR22 RESISTOR, METAL FILM 0.22Ω, 1W
R74 ERJ3GEYJ473B RESISTOR, CHIP 47KΩ, 1/16W
R75 ERJ3GEYJ473B RESISTOR, CHIP 47KΩ, 1/16W
R76 ERJ3GEYJ223B RESISTOR, CHIP 22KΩ, 1/16W
R77 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R78 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R79 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W
R8 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W
R80 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W
R81 ERJ3GEYJ823B RESISTOR, CHIP 83Ω, 1/16W
R82 ERJ3GEYJ823B RESISTOR, CHIP 83Ω, 1/16W
R83 ERJ3GEYJ823B RESISTOR, CHIP 83Ω, 1/16W
R84 ERJ3GEYJ823B RESISTOR, CHIP 83Ω, 1/16W
R85 ERJ3GEYJ823B RESISTOR, CHIP 83Ω, 1/16W
R86 ERJ3GEYJ823B RESISTOR, CHIP 83Ω, 1/16W
R9 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W
R90 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W
R91 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W
R92 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W
R93 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R94 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R95 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
R96 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W
X1 DZDP000162 CRYSTAL UNIT
XIC3 DZFA000044 IC SOCKET
Safety
Mark
RefNo Part Number Part Name Description
1 DZAA001052 FLASH MEMORY
C1 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C10 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C11 DZBA000199 CAPACITOR, CERAMIC 100pF, 50VDC
C12 DZBA000199 CAPACITOR, CERAMIC 100pF, 50VDC
C13 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C14 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C15 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C16 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC
C17 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C18 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C19 EEVHA1V221P CAPACITOR, ELECTROLYTIC 220µF, 35VDC
C2 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C20 EEVHA1H100P CAPACITOR, ELECTROLYTIC 10µF, 50VDC
C21 EEVHA1C100R CAPACITOR, ELECTROLYTIC 10µF, 16VDC
C22 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C23 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C24 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C25 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C26 DZBA000196 CAPACITOR, CERAMIC 470pF, 50VDC
C27 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C28 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C29 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
C3 DZBA000187 CAPACITOR, CERAMIC 27pF, 50VDC
C30 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC
C31 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC
Safety
Mark
Ref. No. Part Number Part Name Description
